Hydraulic Pump, Electric, 0.5 hp, Universal Motor, 10,000 psi Max Pressure - PUD1300B

Hydraulic Pump, Electric, 0.5 hp, Universal Motor, 10,000 psi Max Pressure - PUD1300B

Enerpac
SKU:
PUD1300B
|
UPC:
662005125296
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Hydraulic Pump, Horsepower - Maximum 1/2 hp, Nameplate Voltage 115V AC, Duty Cycle Intermittent, Operating Pressure - Maximum 10,000 psi, Displacement @ 5000 psi 25 cu in/min, Displacement @ 10,000 PSI 20 cu in/min, Control Valve Type 2-Position, 3-Way, Reservoir Capacity 0.5 gal, Reservoir Material Polyethylene, Overall Height 14.3 in, Cylinder Compatibility Single Acting, Charger Input Voltage 115V AC, Control Pendant Size 10 ft, Control Pendant Voltage Manual
Additional Information
Country of Origin:
United States
Promotion Restriction:
Not eligible for promotion
Item:
Hydraulic Pump
Type:
Electric
Reservoir Capacity (Cu.-In.):
115 cu in
Reservoir Capacity (Gal.):
0.5 gal
Oil Displacement @ 100 PSI:
200 cu in/min
Oil Displacement @ 700 PSI:
70 cu in/min
Oil Displacement @ 1000 PSI:
30 cu in/min
Oil Displacement @ 10,000 PSI:
20 cu in/min
Oil Displacement @ 0-200 PSI:
200 cu in/min
HP:
0.5 hp
Maximum Pressure:
10,000 psi
Motor Type:
Universal
Reservoir Material:
Polyethylene
Control Pendant Voltage:
Manual
Control Pendant Size (Ft.):
10 ft
Fluid Port NPT (In.):
3/8
dBA:
85
Application:
Remote Valve Operation
Amps AC:
9.5 A
Control Valve:
Dump and Hold
Relief Valve Range:
1000 to 3000 psi
Voltage:
115
Oil Displacement @ 200-10,000 PSI:
20 to 200 cu in/min
Charger Input Voltage:
115V AC
Displacement @ 10,000 PSI:
20 cu in/min
Horsepower - Maximum:
1/2 hp
Overall Width:
9.6 in
Displacement @ 5000 psi:
25 cu in/min
Displacement @ 700 psi:
70 cu in/min
Control Valve Type:
2-Position, 3-Way
Reservoir Capacity:
0.5 gal
Frequency:
50 Hz, 60 Hz
Sound Level - Maximum:
85 dBA
Operating Pressure - Maximum:
10,000 psi
Media Intake Connection Type:
NPTF
Control Valve Pressure Relief - Maximum:
3,000 psi
Control Valve Function:
Advance, Hold, Retract
Control Valve Pressure Relief - Minimum:
1,000 psi
Displacement @ 1000 psi:
30 cu in/min
Media Intake Connection Size:
1/4 in
Displacement @ 100 psi:
200 cu in/min
Duty Cycle:
Intermittent
Remote Control Cord Length:
10 ft
Flow Rate - Maximum:
20 cu in/min
Control Pendant Size:
10 ft
Nameplate Voltage:
115V AC
Current:
9.5 A
Cylinder Compatibility:
Single Acting
Displacement @ 200 psi:
200 cu in/min
Overall Length:
9.6 in
Overall Height:
14.3 in
Package Quantity:
1
