HVAC Motor, Totally Enclosed Fan-Cooled, 1/8 HP, 3,000 Nameplate RPM, 1 Speed, 115V AC, 1.3 A - 71626626M

HVAC Motor, Totally Enclosed Fan-Cooled, 1/8 HP, 3,000 Nameplate RPM, 1 Speed, 115V AC, 1.3 A - 71626626M

Dayton
SKU:
71626626M
|
UPC:
190735291702
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
The DAYTON - 71626626M is a HVAC Motor, specifically designed for the operation of heating, ventilation, and air conditioning units. It's primarily used in both commercial and residential settings to maintain optimal environmental conditions.Key Features: • Nameplate RPM of 3000 provides precise control over pneumatic tools' performance. • High horsepower (HP: 1/8) indicates greater capacity to drive pneumatic tools efficiently. • Ring/Stud mounting type offers diverse solutions for different industrial needs. • Auto thermal protection prevents overheating by automatically shutting down when excessive heat is detected. • Voltage requirement:115V AC • Sleeve motor bearings reduce friction enhancing operational efficiency • CSA Certified (244617), UL Recognized (E37403) standards ensure quality, safety, and efficiency • Maximum ambient temperature:40 Degrees C • Full Load Amps at 1.3 A ensures appropriate power supply avoiding overload for optimal performance • CW/CCW shaft rotation crucial for proper operation and compatibility with specific industrial applications • Single phase power supply suited for residential or light commercial use • Totally Enclosed Fan-Cooled enclosure design protects against dust & moisture • Duty Cycle: Continuous allowing non-stop operation for high-demand settings
Additional Information
Country of Origin:
Mexico
Voltage:
115V AC
Nameplate RPM:
3,000
Motor Enclosure Design:
Totally Enclosed Fan-Cooled
Number of Speeds:
1
HP:
1/8
RPM Range:
1,801-3,000
Shaft Length:
2 5/16 in
Cord Length:
12 in
No. of Speeds:
1
Item:
HVAC Motor
Application:
OEM and Replacement Use In A Wide Variety of Fan and Blower
Mounting Stud Location:
4/Shaft End
Motor Mounting Type:
Ring/Stud
Frame:
3.3
Number of Shafts:
1
Motor Thermal Protection:
Auto
Motor Design:
Permanent Split Capacitor
Stud/Base Mtg. Pattern:
2 in x 2 in
Motor Application:
HVAC/R
Full Load Amps:
1.3 A
Includes:
Capacitor
Length Less Shaft:
5 15/16 in
Motor Shaft Rotation:
CW/CCW
Motor Bearings:
Sleeve
Capacitor Required:
Included
Standards:
CSA Certified (244617), UL Recognized (E37403)
Mounting Pattern:
2 x 2
Phase:
Single
Max. Ambient Temp.:
40 Degrees C
Duty:
Continuous
Motor Shaft Design:
Flat
Hz:
60 Hz
Motor Service Factor:
1
Voltage Compatibility:
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Ins. Class:
B
Body Dia.:
4 in
Shaft Dia.:
5/16 in
Motor Sub Application:
Direct Drive Fan/Blower
Mounting Stud Pattern:
2 in x 2 in
Duty Cycle:
Continuous
Motor Mounting Position:
All Angle
Usable @ 200V:
No
Usable @ 208V:
No
Type:
OEM Replacement
Package Quantity:
1
