Hot Water Circulating Pump, 3/4 hp, 208V/230V/460V, 3 Phase, Flange Connection - 116480LF-137A

Hot Water Circulating Pump, 3/4 hp, 208V/230V/460V, 3 Phase, Flange Connection - 116480LF-137A

Armstrong Pumps
SKU:
116480LF-137A
|
UPC:
672807403423
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Potable Water Circulating Pump, Compatible Intake Pipe Size 1 1/2 in, Connection Type Flange, Face to Face Dimension 13 1/2 in, Flange or Union Included Yes, For Use With Potable Systems Yes, Horsepower 3/4, Maximum Feet of Head 46 ft, Maximum Flow Rate @ 10 Feet of Head 85 gpm, Maximum Flow Rate @ 15 Feet of Head 80 gpm, Maximum Flow Rate @ 1 Foot of Head 100 gpm, Nameplate Voltage 208-240/460V AC, Number of Speeds 1, Phase Three, Pump Type 3-Piece, Series Family S&H
Additional Information
Country of Origin:
United States
Item:
Potable Water Circulating Pump
Voltage:
208-240/460V AC
Phase:
Three
Horsepower:
3/4
Series:
H-64
Inlet/Outlet Size:
1-1/2 in
Pump Type:
3-Piece
Number of Speeds:
1
Max. GPM @ Head:
62 gpm @ 13 ft
Maximum Feet of Head:
46 ft
Min. GPM @ Head:
15 gpm @ 44 ft
Connection Type:
Flange
Shaft Material:
Carbon Steel
Best Efficiency GPM @ Head:
40 gpm @ 37 ft
Includes:
(2) Flanges, and (2) Gaskets, Nuts and Bolts
Amps:
1.4/2.7/2.8 A
Mechanical Seal:
Silicon Carbide Mechanical Seal
Impeller Material:
Non-Ferrous Metal
Face to Face Dimension:
13 1/2 in
Thermal Protection:
yes
Shut-Off:
45 ft
Pump Mount:
In Line
Compliance:
cUL, Low Lead, NSF-372
Drive Type:
Direct
Standards:
NSF-372
Loop Configuration:
Open
Features:
3 Piece Oil Lubricated Booster
Overall Length:
23 in
Overall Width:
10 in
Overall Height:
13.5 in
Compatible Media Type:
Water
Pipe to Flange or Union Connection Type:
FNPT
Maximum Flow Rate @ 40 Feet of Head:
30 gpm
Body Gasket Material:
Sintered Silicon Carbide
Flange or Union Included:
Yes
Maximum Flow Rate @ 50 Feet of Head:
[DELETE]
Series Family:
S&H
For Use With Potable Systems:
Yes
Maximum Flow Rate @ 15 Feet of Head:
80 gpm
Maximum Flow Rate @ 10 Feet of Head:
85 gpm
Compatible Intake Pipe Size:
1 1/2 in
Maximum Media Temperature:
225 Degrees F
Maximum Flow Rate @ 25 Feet of Head:
52 gpm
Nameplate Voltage:
208-240/460V AC
Maximum Operating Pressure:
175 psi
Maximum Flow Rate @ 1 Feet of Head:
100 gpm
Pump Housing Material:
Bronze
Manufacturer Warranty Length:
2 yr
Maximum RPM:
1,750 RPM
Maximum Flow Rate @ 20 Feet of Head:
75 gpm
Maximum Flow Rate @ 30 Feet of Head:
47 gpm
Maximum Flow Rate @ 5 Feet of Head:
95 gpm
Package Quantity:
1
