Heavy Duty Hoist Ring, 5000 lb. WLL - 33714

Heavy Duty Hoist Ring, 5000 lb. WLL - 33714

Adb Hoist Rings
SKU:
33714
|
UPC:
43927337149
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Hoist Ring, Movement Type Pivot, Swivel, Material Alloy Steel, Mount Type Screw-On, Working Load Limit 5,000 lb, Thread Size 3/4 In.-10, Operation Lifting, Pulling, Pivot Angle 180 Degrees , Swivel Angle 360 Degrees , Usable Thread Length 1 in, Bail Inside Length 2 1/4 in, Bail Inside Width 1 7/8 in, Bail Thickness 3/4 in, Overall Length 3 1/2 in, Overall Width 3 1/2 in, Hardware Included Removable Bolt, Minimum Installation Torque 100 ft-lb, Finish Black Oxide
Additional Information
Country of Origin:
United States
Item:
Hoist Ring
Mounting Style:
Screw-On
Series:
Heavy Duty(R)
Pivot:
180 Degrees
Swivel Angle:
360 Degrees
Working Load Limit:
5,000 lb
Bail Dia.:
3/4 in
Thread Size:
3/4-10"
Dimension C:
1 1/2 in
Dimension B:
3 1/2 in
Standards:
ANSI/ASME B30.26, MIL-STD-209
Dimension F:
5 5/16 in
Dimension E:
1 in
Installation Torque:
100 ft-lb
Mount Type:
Screw-On
Color:
Black
Overall Width:
3 1/2 in
Minimum Operating Temperature:
-20 Degrees F
Movement Type:
Pivot, Swivel
Material:
Alloy Steel
Finish:
Black Oxide
Minimum Installation Torque:
100 ft-lb
Usable Thread Length:
1 in
Bail Thickness:
3/4 in
Overall Length:
3 1/2 in
Maximum Operating Temperature:
400 Degrees F
Pivot Angle:
180 Degrees
Bail Inside Length:
2 1/4 in
Bail Inside Width:
1 7/8 in
Hardware Included:
Removable Bolt
Operation:
Lifting, Pulling
Package Quantity:
1
