Grinder Pump System, Simplex, 230V - P382XPRG102
Liberty PumpsLog in for pricing
(No reviews yet)
Write a Review
Liberty Pumps
Grinder Pump System, Simplex, 230V - P382XPRG102
Grinder Pump System, Simplex, 1 HP, Switch Type Wide Angle, Voltage 230, Amps 6, Height 24 In., Dia. 25 In., Cord Length 10 Ft., Discharge NPT 2 In., Shaft Seal SIC, Off Point 4.6 In., On Point 11.6 In., Max. Head 50 Ft., Max. Temp. 140 Degrees F, 1 Phase
- Country of Origin:
- United States
- HP:
- 1 hp
- Phase - Pumps:
- 1
- Switch Actuation:
- Tether Float
- Base Material:
- Cast Iron
- Flow Rate @ 10 Ft. of Head:
- 42 gpm
- Max. Head:
- 50 ft
- Impeller Material:
- Cast Iron
- GPM of Water @ 10 Ft. of Head:
- 42
- GPM of Water @ 15 Ft. of Head:
- 39
- Max Head - Pumps:
- 50 ft.
- GPM of Water @ 35 Ft. of Head:
- 22
- Item:
- Grinder Pump System
- Impeller Material - Pumps:
- Stainless Steel
- Switch Type - Pumps:
- Wide Angle Float
- Amps:
- 6 A
- Switch Type:
- Wide Angle
- Shaft Seal:
- SIC
- Phase:
- 1
- Voltage:
- 230
- Pump HP:
- 1
- Input Phase AC:
- 1
- Discharge NPT:
- 2 F"
- Item - Sump/Sewage Pump Systems:
- Grinder Pump System
- GPM of Water @ 40 Ft. of Head:
- 15
- GPM of Water @ 30 Ft. of Head:
- 27
- Hz:
- 60
- Thermal Protection:
- yes
- Duty:
- Intermittent
- Height:
- 24";GPM of Water @ 5 Ft. of Head=44"
- GPM of Water @ 45 Ft. of Head:
- 10
- Agency Compliance:
- CSA, UL 778
- Cord Length:
- 10 ft
- Diameter:
- 24-3/8";Max. Liquid Temp.=140 Degrees F"
- GPM of Water @ 20 Ft. of Head:
- 36
- GPM of Water @ 25 Ft. of Head:
- 32
- Amps - Pumps:
- 6.00
- Handle:
- yes
- Cord Length - Pumps:
- 10 ft.
- Bearing Type:
- Ball
- Voltage - Pumps:
- 230VAC
- On Point:
- 11.6 in
- Off Point:
- 4.6 in
- Manufacturers Warranty Length:
- 3 yr
- Max. Head - Pumps:
- 50 ft.
- Motor Type:
- CSCR
- Motor RPM:
- 3450
- Pump Body Material:
- Cast Iron
- Max. Diameter Solids:
- 2 in
- RPM:
- 3,450 RPM
- Inlet:
- 4 in FNPT
- Flow Rate @ 20 Ft. of Head:
- 36 gpm
- Switch Electrical Connection:
- Integral
- Flow Rate @ 30 Ft. of Head:
- 27 gpm
- Number of Pumps:
- 1
- Duty Cycle:
- Intermittent
- Flow Rate @ 15 Ft. of Head:
- 39 gpm
- Inlet Dia.:
- 4 in
- Vent Size:
- 2 in /3 in
- Inlet Standard:
- NPT
- Flow Rate @ 5 Ft. of Head:
- 44 gpm
- Inlet Gender:
- Female
- Rated Voltage:
- 230V AC
- Package Quantity:
- 1
-
-
