Gear, Spur, 8 Pitch - NH32A

Gear, Spur, 8 Pitch - NH32A

Boston Gear
SKU:
NH32A
|
UPC:
781711103746
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Spur Gear, Bore Diameter 1 in, Hub Diameter 3 in, Hub Projection 0.88 in, Face Width 1 1/4 in, Pitch Diameter 4 in, Material Steel, Pressure Angle 14.5 Degrees , Compatible Gear Rack Grainger Part Number 1L905, 1L906, Compatible Gear Rack Manufacturer Part Number L518-6, L519-6, Diametral Pitch 8, Keyway No
Additional Information
Country of Origin:
United States
Item:
Spur Gear
Pitch:
8
Pitch Dia. (In.):
4 in
Face Width (In.):
1.25 in
Number of Teeth:
32
Bore Dia. (In.):
1 in
Outside Dia. (In.):
4.25 in
Material:
Steel
Hub Dia. (In.):
3 in
Setscrew:
Not Included
For Use With:
1L905, 1L906
Function:
Transmitting Motion and Power Between Parallel Shafts, Minimizes Backlash to Perform Smooth and Quiet Operation, Close Concentricity Between Bore, Pitch Diameter and Outside Diameter Facilitates Reboring Modifications
Keyway:
N
Overall Length (In.):
2.13 in
Hub Projection (In.):
0.88 in
Pressure Angle (Deg.):
14.5
Agency Compliance:
AGMA
Bore Diameter:
1 in
Compatible Gear Rack Manufacturer Part Number:
L518-6, L519-6
Outside Diameter:
4.25 in
Hub Projection:
0.88 in
Pressure Angle:
14.5 Degrees
Hub Diameter:
3 in
Standards:
AGMA
Overall Length:
2.13 in
Face Width:
1 1/4 in
Diametral Pitch:
8
System of Measurement:
Inch
Pitch Diameter:
4 in
Package Quantity:
1
