Fuel Transfer Pump, 12V DC, 15 gpm Max. Flow Rate , 1/4 HP, Cast Iron, 1 in MNPT Inlet - FR1211H

Fuel Transfer Pump, 12V DC, 15 gpm Max. Flow Rate , 1/4 HP, Cast Iron, 1 in MNPT Inlet - FR1211H

Fill-Rite
SKU:
FR1211H
|
UPC:
89404223109
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Fuel Transfer Pump, Max. Head Pressure 16 psi, Max. Outlet Pressure 16 psi, For Use With Bio-Diesal up to B20 E15. Kerosene, Diesel, Gasoline, Rated Voltage 12V DC, Hose Length 12 ft, Suction Tube Length 40 in, Cord Length 18 ft, Runs Dry Yes, Nozzle Operation Manual, Thermal Protection Yes, Power Source Electric, Includes Discharge Hose Yes, Self-Priming Yes, Compatible Chemicals Biodiesel, Diesel, Ethanol, Gasoline, Kerosene, Mineral Spirits, Discharge Connection Type NPT
Additional Information
Country of Origin:
United States
Voltage:
12V DC
Application:
Farming; Construction
HP:
1/4
Housing Material:
Cast Iron
GPM:
15 gpm
Inlet Size:
1 in MNPT
Seal Material:
Carbon, Ceramic
RPM:
2600
Pump Design:
Rotary Vane
Self-Priming:
Yes
Seal Type:
O-ring
Max. Viscosity:
39.5 SUS
Item:
Fuel Transfer Pump
Hose Length:
12 ft
Pressure Range:
0 psi to 16 psi
Bearing Type:
Sealed Ball
Suction Tube Length:
40 in
Amps AC:
4.9
Bypass Valve:
Internal
Includes:
Cable, Discharge Hose, Meter, Nozzle
Duty Cycle:
30 Minutes On/30 Minutes Off
Metered:
Yes
Nozzle Type:
Manual
Outlet Size:
1 in FNPT
Manufacturers Warranty Length:
2 yr
Overall Height:
18 in
For Use With:
Bio-Diesal up to B20 E15. Kerosene, Diesel, Gasoline
Hose Dia.:
3/4 in
Nozzle Material:
Aluminum
Standards:
UL/cUL Motor
Transfer Pump Application:
Agriculture, Construction, Farming
Features:
Explosion Proof Motor, Thermal Overload Protection
Overall Length:
18 1/4 in
Overall Width:
18 5/8 in
Compatible Fluids:
Biodiesel up to B20, Diesel, E15, Gasoline, Kerosene
Power Cord Length:
18 ft
Motor Enclosure:
Explosion Proof
Cord Length:
18 ft
Agency Compliance:
cULus
Wetted Materials:
Buna-N, Ceramic, Cork, Stainless Steel, Steel, Thermoset, Viton
Motor Type:
Permanent Magnet
Max. Head - Pumps:
37 ft
Housing Material - Pumps:
Cast Iron
Motor RPM:
2,600 RPM
Pump Connection Type:
NPT
Explosion Proof:
Yes
Hose Outside Dia.:
3/4 in
Thermal Protection:
Yes
Rated Voltage:
12V DC
Includes Nozzle:
Yes
Mount Type:
Bung
For Container Size:
275 gal
Includes Suction Tube:
Yes
Max. Outlet Pressure:
16 psi
For Media Type:
Biodiesel, Diesel, Ethanol, Gasoline, Kerosene, Mineral Spirits
Meter Type:
Mechanical
Meter Unit Of Measure:
Gallons
Motor HP:
1/4 hp
Nozzle Operation:
Manual
Full Load Amps:
26.0 A
Discharge Connection Type:
NPT
Nozzle Fluid Compatibility:
Diesel
Runs Dry:
Yes
Power Source:
Electric
Compatible Chemicals:
Biodiesel, Diesel, Ethanol, Gasoline, Kerosene, Mineral Spirits
Includes Discharge Hose:
Yes
Max. Head Pressure:
16 psi
Filter Included:
Not Applicable
Max. Flow Rate:
15 gpm
Package Quantity:
1
