Fuel Transfer Pump, 115/230V AC, 35 gpm Max. Flow Rate , 3/4 HP, Cast Iron - FR311VB

Fuel Transfer Pump, 115/230V AC, 35 gpm Max. Flow Rate , 3/4 HP, Cast Iron - FR311VB

Fill-Rite
SKU:
FR311VB
|
UPC:
89404090602
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Fuel Transfer Pump, Max. Head Pressure 26 psi, Max. Outlet Pressure 26 psi, For Use With Diesel, Rated Voltage 230V AC, Hose Length 18 ft, Suction Tube Length No, Cord Length 1 ft, Nozzle Operation Automatic, Power Source Electric, Includes Discharge Hose Yes, Self-Priming Yes, Compatible Chemicals B20, Diesel, E15, Gasoline, Kerosene, Discharge Connection Type NPT, Features Explosion Proof Motor, Thermal Overload Protection, Includes Nozzle Yes, Nozzle Material Aluminum
Additional Information
Country of Origin:
United States
Voltage:
115/230V AC
Application:
For Use With Above Ground and Underground Tanks
HP:
3/4
Housing Material:
Cast Iron
GPM:
35 gpm
Inlet Size:
Inlet Size, Bung
Seal Material:
Carbon
RPM:
1725/1425
Pump Design:
Rotary Vane
Self-Priming:
Yes
Seal Type:
O-ring
Max. Viscosity:
50 SUS
Item:
Fuel Transfer Pump
Features:
Explosion Proof Motor, Thermal Overload Protection
Amps AC:
9.8/4.9/11.4/5.7
Overall Width:
17 in
Standards:
cUL, UL
Pressure Range:
0 psi to 26 psi
Suction Tube Length:
No
Transfer Pump Application:
Agriculture, Construction, Farming
Overall Length:
15 in
Hose Dia.:
1 in
Outlet Size:
1 in
Overall Height:
19 1/4 in
Nozzle Type:
Automatic
Manufacturers Warranty Length:
2 yr
Includes:
Cable, Discharge Hose, Meter, Nozzle
For Use With:
Diesel
Metered:
Yes
Duty Cycle:
30 Minutes On/30 Minutes Off
Hose Length:
18 ft
Compatible Fluids:
B20, Diesel, E-15, Gasoline, Kerosene
Bypass Valve:
Internal
Nozzle Material:
Aluminum
Bearing Type:
Sealed Ball
Motor Enclosure:
Explosion Proof
Cord Length:
1 ft
Motor Type:
Permanent Magnet
Agency Compliance:
cULus
Max. Head - Pumps:
60 ft
Motor RPM:
1,725 RPM
Housing Material - Pumps:
Cast Iron
Nozzle Fluid Compatibility:
Diesel
Hose Outside Dia.:
1 in
For Media Type:
B20, Diesel, E15, Gasoline, Kerosene
Meter Unit Of Measure:
Gallons
Max. Flow Rate:
35 gpm
Nozzle Operation:
Automatic
Meter Type:
Mechanical
For Container Size:
10,000 gal
Max. Outlet Pressure:
26 psi
Explosion Proof:
Yes
Includes Nozzle:
Yes
Discharge Connection Type:
NPT
Max. Head Pressure:
26 psi
Power Source:
Electric
Pump Connection Type:
NPT
Mount Type:
Bung
Motor HP:
3/4 hp
Includes Discharge Hose:
Yes
Full Load Amps:
11.4 A
Rated Voltage:
230V AC
Compatible Chemicals:
B20, Diesel, E15, Gasoline, Kerosene
Package Quantity:
1
