Fuel Transfer Pump, 10 gpm Max. Flow Rate , Cast Iron, 1 in NPT Inlet - FR113

Fuel Transfer Pump, 10 gpm Max. Flow Rate , Cast Iron, 1 in NPT Inlet - FR113

Fill-Rite
SKU:
FR113
|
UPC:
89404003008
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Fuel Transfer Pump, Max. Outlet Pressure 38 psi, Pump Connection OD 2 1/8 in, Spout Connection Size 3/4 in, Self-Priming Yes, Metered No, Hose Length Not Applicable, Includes Discharge Hose No, Features Anti-Siphon Valve, Can Be Used to Pump In Reverse Direction, Rotary Hand Pump, Seal Material Carbon, For Use With Diesel/Fuel Oil, Adapter Connection Type MNPT, For Container Type Drum, Hose Cover Material Not Applicable, Includes Bung Adapter Yes, Includes Nozzle No, Includes Spout Yes
Additional Information
Country of Origin:
United States
Application:
Ideal For Use with Drums and Barrels in Low Volume Applications
Housing Material:
Cast Iron
GPM:
10 gpm
Inlet Size:
1 in NPT
Seal Material:
Carbon
Pump Design:
Rotary
Self-Priming:
Yes
Seal Type:
Mechanical
Max. Viscosity:
50 SUS
Item:
Fuel Transfer Pump
Outlet Size:
3/4 in NPT
Overall Height:
15 1/2 in
Features:
Anti-Siphon Valve, Can Be Used to Pump In Reverse Direction, Rotary Hand Pump
Compatible Fluids:
Biodiesel up to B20, Diesel, E15, Gasoline, Kerosene
Transfer Pump Application:
Agriculture, Construction, Farming
Suction Tube Length:
20 in to 34 1/2 in
Standards:
UL Listed
Includes:
Spout, Suction Pipe
Pump Mount Size:
2 in
Bypass Valve:
No
Overall Length:
6 1/4 in
For Use With:
Diesel/Fuel Oil
Pressure Range:
38 psi
Overall Width:
9 1/2 in
Manufacturers Warranty Length:
2 yr
Metered:
No
Agency Compliance:
cUL/UL Listed
Duty Cycle:
Continuous
Action Type:
Rotary
Hose Length:
Not Applicable
Nozzle Material:
Not Applicable
Wetted Materials:
301 Stainless Steel, Buna-N, Cast Iron, Zinc Plated Steel
Housing Material - Pumps:
Aluminum
Hose Inside Dia.:
Not Applicable
Max. Flow Rate:
10 gal per 100 revolutions
Hose Outside Dia.:
Not Applicable
For Container Type:
Drum
Max. Fluid Temp.:
120 Degrees F
Includes Nozzle:
No
Spout Material:
Aluminum
For Container Size:
55 gal
Compatible Chemicals:
Diesel Fuel, Gasoline, Kerosene, Light Oil
Max. Head Pressure:
50 psi
Suction Tube Material:
Steel
Includes Spout:
Yes
Pump Connection OD:
2 1/8 in
Includes Bung Adapter:
Yes
Hose Cover Material:
Not Applicable
Adapter Connection Type:
MNPT
Spout Connection Size:
3/4 in
Hose Tube Material:
Not Applicable
Bung Connection Dia.:
2 in
Mount Type:
Bung
Includes Discharge Hose:
No
Max. Outlet Pressure:
38 psi
Includes Suction Tube:
Yes
For Media Type:
Diesel Fuel, Gasoline, Kerosene, Light Oil
Nozzle Operation:
Not Applicable
Package Quantity:
1
