Exhaust Ventilator, 3/4 hp, 30 in Blade Dia., 115V AC/230V AC, Belt Drive - 7A408

Exhaust Ventilator, 3/4 hp, 30 in Blade Dia., 115V AC/230V AC, Belt Drive - 7A408

Dayton
SKU:
7A408
|
UPC:
799471519479
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Axial Downblast Roof Exhaust Fan, Mounting Location Roof, Assembly Unassembled, Blade Diameter 30 in, Housing Material Aluminum, Exhaust Airflow @ 0.000 in SP 5,810 cfm, For High-Static Pressure Applications No, High-Efficiency Motor No, Maximum Static Pressure 5/8 in wc, Motor Enclosure Open Dripproof, Motor Horsepower 3/4 hp, Nameplate Voltage 115/208-230V AC, Number of Speeds 1, Phase 1, Maximum Inlet Air Temperature 120 Degrees F, Number of Blades 5, Supply Airflow @ 0.000 in SP 5,810 cfm
Additional Information
Country of Origin:
Multiple
Item - Roof Ventilators:
Exhaust Ventilator
Item:
Axial Downblast Roof Exhaust Fan
Drive Package With Motor Included:
Yes
Drive Type - Roof Ventilators:
Belt Drive
Blade Dia.:
30 in
Voltage - Roof Ventilators:
115V AC/230V AC
Motor HP - Roof Ventilators:
3/4 hp
CFM @ 0.000-In. SP:
5,810 cfm
Base Size - Roof Ventilators:
42 in x 42 in
CFM @ 0.250-In. SP:
4,369 cfm
CFM @ 0.675-In. SP:
1,685 cfm
Includes:
Drive Package, NEMA 1 Junction Box
Base Length (In.):
42
Bearing Type:
Regreasable Pillow Block
Housing Material:
Aluminum
Max. Operating Amps:
13.8/6.9
Base Square Size - Roof Ventilators:
42 x 42""
Stock No.:
4YU90
Propeller Material:
Steel
Dimension C (In.):
34 3/8
Motor HP:
3/4
Max. BHP:
0.8 hp
Base Width (In.):
42
Agency Compliance:
UL And C-UL Listed
Speed Controllable:
No
Requires:
Roof curb for new installations
Mounting Location:
Roof
Recommended 12 In. Fixed Curb Item No.:
2RB81
Recommended Damper Stock No.:
4HX69
Base Height (In.):
1 3/4 in
CFM @ 0.500-In. SP:
2,631 cfm
Dimension B (In.):
47.5
Adj. 6 3/8H Roof Curb Stock No.:
4c455"
Dimension C:
34 3/8 in
Phase:
1
Motor Voltage:
115/230
Dimension A:
42 in
Assembled/Unassembled:
Unassembled
Adj. 12 3/8H Roof Curb Stock No.:
2ZV84"
RPM:
631 RPM
Drive Package Included:
Yes
Max. Inlet Temp. (Deg. F):
120 Degrees F
CFM @ 0.125-In. SP:
5,139 cfm
Application:
Industrial and Commercial Applications
Dimension A (In.):
42
Motor HP Range:
1/2 to 2
Type:
Axial Belt Drive Downblast with Drive Package
Recommended Damper Size (In.):
35 x 35
Recommended 8 In. Fixed Curb Item No.:
4HX43
Shaft Dia. Propeller End (In.):
1 1/4 in
Motor Hz:
60 Hz
Dimension D:
4 3/4 in
Overall Dia. (In.):
47 1/2 in
Propeller Dia. (In.):
30
CFM @ 0.375-In. SP:
3,571 cfm
Dimension D (In.):
4.75
Shaft Dia. Sheave End (In.):
1 1/4 in
Overall Height (In.):
36 1/8 in
Dimension B:
47 1/2 in
Base Height:
1 3/4 in
Nameplate Voltage:
115/208-230V AC
Motor Location:
Out of Airstream
Maximum Static Pressure:
5/8 in wc
Number of Blades:
5
Frequency:
60 Hz
Assembly:
Unassembled
Supply Airflow @ 0.000 in SP:
5,810 cfm
Safety Features:
Birdscreen, Windband
Motor Enclosure:
Open Dripproof
Propeller Shaft Diameter:
1 in
Maximum Ambient Temperature:
120 Degrees F
Housing Material Fabrication:
Spun
Overall Height:
36 1/8 in
Standards:
AMCA Sound and Air, UL/cUL 705
Electrical Connection:
Power Cord
Blade Design:
Swept Steeply Pitched
Base Shape:
Square
Includes Drive Package:
Yes
Base Diameter:
Not Applicable
High-Efficiency Motor:
No
Maximum Fan Speed:
631 RPM
Mount Type:
Roof Curb
Resistance Properties:
Weather Resistant
Base Length:
42 in
Overall Length:
47 1/2 in
For Air Type:
Clean Air
Base Width:
42 in
Exhaust Airflow @ 0.500 in SP:
2,631 cfm
Airflow @ 0.000 in SP:
5,810 cfm
Exhaust Airflow @ 0.375 in SP:
3,571 cfm
Exhaust Airflow @ 0.000 in SP:
5,810 cfm
Brake Horsepower:
4/5 hp
Current:
11.6/5.9-5.8 A
Housing Length:
47.5 in
Number of Speeds:
1
Overall Diameter:
Not Applicable
Maximum Inlet Air Temperature:
120 Degrees F
For High-Static Pressure Applications:
No
Exhaust Airflow @ 0.250 in SP:
4,369 cfm
Features:
Fully Rolled Bead on the Windband Ensures Stability and Provides Rigidity for Lifting and Transporting, NEMA 1 Junction Box Located in Motor Enclosure
Blade Material:
Steel
Blade Diameter:
30 in
Includes Motor:
Yes
Motor Horsepower:
3/4 hp
Exhaust Airflow @ 0.125 in SP:
5,139 cfm
Damper Size:
35 x 35 in
Drive Type:
Belt Drive
Compatible Curb Manufacturer Part Number:
2RB81, 2ZV84, 3C438, 4C455, 4HX43, 4HX51
Housing Width:
47.5 in
Overall Width:
47 1/2 in
Package Quantity:
1
