Exhaust Ventilator, 17in.H, 24-5/8in.dia - 39FV53

Exhaust Ventilator, 17in.H, 24-5/8in.dia - 39FV53

Dayton
SKU:
39FV53
|
UPC:
190735277713
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Axial Downblast Roof Exhaust Fan, Mounting Location Roof, Assembly Assembled, Blade Diameter 10 in, Housing Material Aluminum, Exhaust Airflow @ 0.000 in SP 542 cfm, For High-Static Pressure Applications No, High-Efficiency Motor Yes, Maximum Static Pressure 3/8 in wc, Motor Enclosure Open Dripproof, Motor Horsepower 1/4 hp, Nameplate Voltage 115V AC, Number of Speeds 1, Phase 1, Maximum Inlet Air Temperature 120 Degrees F, Number of Blades 4, Supply Airflow @ 0.000 in SP 542 cfm
Additional Information
Country of Origin:
United States
Item:
Axial Downblast Roof Exhaust Fan
Propeller Dia.:
10 in
Voltage:
115
Motor HP:
1/4 hp
Speed Control:
Variable with 43Y140
Sones @ 0.250-In. SP @ 5 Ft.:
-/-/12.5
Base Top to Shroud:
5 1/2 in
Mounting Location:
Roof or Wall
CFM @ 0.500-In. SP:
-/-/-
Shaft Dia. Propeller End:
1/2 in
Requires:
Roof Curb For New Installation
CFM @ 1.000-In. SP:
-/-/-
Adj. 12 3/8H Roof Curb Stock No.:
2ZV82"
Recommended 8 In. Fixed Curb Item No.:
4HX38
Housing Material:
Aluminum
Recommended Damper Size:
12 in x 12 in
Overall Height:
17 in
Dimension A:
19 in
Recommended Damper Stock No.:
4HX64
Max. Inlet Temp.:
120 Degrees F
Hz:
60
Dimension B:
24 5/8 in
CFM @ 1.250-In. SP:
-/-/-
CFM @ 0.750-In. SP:
-/-/-
CFM @ 0.875-In. SP:
-/-/-
RPM:
860/1140/1725
Base Width:
19 in
CFM @ 0.125-In. SP:
199/457
Propeller Material:
Aluminum
Standards:
AMCA Sound and Air, UL/cUL 705
Dimension C:
15 1/4 in
CFM @ 0.375-In. SP:
-/-/246
Speed Controllable:
Yes
Dimension D:
5 1/2 in
CFM @ 0.625-In. SP:
-/-/-
CFM @ 0.000-In. SP:
270/358/542
Includes:
NEMA 1 Junction Box
Base Height:
1 3/4 in
Sones @ 0.125-In. SP @ 5 Ft.:
-/3.7/10.0
Max. BHP:
0.01 hp, 0.04 hp
CFM @ 0.250-In. SP:
-/-/333
Base Length:
19 in
Overall Dia.:
24 5/8 in
Recommended 12 In. Fixed Curb Item No.:
2RB75
Phase:
1
Adj. 6 3/8H Roof Curb Stock No.:
4c453"
Maximum Static Pressure:
3/8 in wc
Assembly:
Assembled
Overall Diameter:
24.6 in
Exhaust Airflow @ 0.250 in SP:
333 cfm
Overall Width:
24 5/8 in
Includes Motor:
Yes
Blade Material:
Aluminum
Overall Length:
24 5/8 in
Number of Blades:
4
Housing Width:
24.6 in
Features:
Fully Rolled Baffle Bead for Stability and Ease of Transport With Spun Aluminum Hood Construction, Galvanized Steel Venturi, Inlet and Supports, Motor Accepts An External 0-10 VDC Control Signal, NEMA 1 Junction Box Located in Motor Enclosure
Housing Length:
24.6 in
Motor Enclosure:
Open Dripproof
Housing Material Fabrication:
Spun
Maximum Inlet Air Temperature:
120 Degrees F
Electrical Connection:
Power Cord
Exhaust Airflow @ 0.000 in SP:
542 cfm
Motor Type:
Electronically Commutated
Cutout Length:
14.5 in
Drive Type:
Direct Drive
Safety Features:
Birdscreen
Supply Airflow @ 0.000 in SP:
542 cfm
For Air Type:
Clean Air
Sound Level:
Fan RPM 1140
Propeller Shaft Diameter:
1/2 in
Blade Diameter:
10 in
High-Efficiency Motor:
Yes
Compatible Curb Manufacturer Part Number:
2RB75, 2ZV82, 4C453, 4C670, 4HX38, 4HX46
For High-Static Pressure Applications:
No
Base Shape:
Square
Motor Horsepower:
1/4 hp
Exhaust Airflow @ 0.125 in SP:
457 cfm
Damper Size:
12 x 12 in
Maximum Fan Speed:
1,725 RPM
Compatible Speed Control:
35YV92, 35YV93, 35YV94, 43Y140
Nameplate Voltage:
115V AC
Includes Drive Package:
Yes
Current:
3.9 A
Exhaust Airflow @ 0.375 in SP:
246 cfm
Number of Speeds:
1
Brake Horsepower:
1/100 hp, 1/25 hp
Mount Type:
Roof Curb
Frequency:
60 Hz
Cutout Size:
14.5 in L x 14.5 in W
Base Diameter:
Not Applicable
Airflow @ 0.000 in SP:
542 cfm
Package Quantity:
1
