Exhaust Fan, 24 In, 3 Phase, Haz Location - 10E007

Exhaust Fan, 24 In, 3 Phase, Haz Location - 10E007

Dayton
SKU:
10E007
|
UPC:
190735109304
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Panel Exhaust Fan, Assembled Assembled, Blade Diameter 24 in, Blade Material Aluminum, Drive Type Direct Drive, Duct Diameter Not Applicable, Exhaust Airflow @ 0.000 in SP 6,317 cfm, For Cut-Out Width 26 1/2 in, Frame Finish Zinc Plated, Frame Material Steel, Guard Type None, Hazardous Location Class Class I, Div 1, Group C and D; Class II, Div 1, Group F and G, Housing Material Steel, Housing Finish Galvanized, Includes Hazardous Location Motor, Includes Dehumidistat No
Additional Information
Country of Origin:
Mexico
Item:
Panel Exhaust Fan
Motor RPM:
1,750 RPM
Width (In.):
28 in
Dimension A (In.):
28 in
Dimension B (In.):
12 in
Venturi Depth (In.):
3 3/8 in
Hz:
60
Motor Insulation:
Class B
Frame Material:
Steel
Full Load Amps:
3.2-3/1.5
Frame Finish:
Zinc Plated
Mounting Position:
Vertical or Horizontal
Number of Blades:
3
Drive Package With Motor Included:
No
CFM @ 0.125-In. SP:
5,851 cfm
Shaft Dia. (In.):
5/8 in
Motor Enclosure:
Totally Enclosed Fan Cooled
CFM @ 0.500-In. SP:
4,117 cfm
Propeller Material:
Aluminum
For Use With:
NEC Class I, Div 1, Group C and D; NEC Class II, Div 1, Group F and G
Aluminum Wall Shutter No.:
3C308
CFM @ 0.000-In. SP:
6,317 cfm
Dimension C (In.):
3 7/8 in
Height (In.):
28 in
Intake Guard No.:
1WBU3
Agency Compliance:
UL and cUL Listed, AMCA, CSA Certified Motor
Flange Width (In.):
1 in
Max. Ambient Temp. (F):
104 Degrees F
Type:
Direct Drive, Hazardous Location
Blade Dia.:
24 in
Watts:
559 W
CFM @ 0.250-In. SP:
5,314 cfm
Exhaust/Supply Fan Item:
Exhaust Fan
Dimension D (In.):
24 1/2 in
CFM @ 0.375-In. SP:
4,729 cfm
Drive Package Included:
No
Phase:
3
Sones @ 0.000-In. SP @ 5 Ft.:
28
Max. Depth (In.):
11 5/16 in
Fan Voltage:
208-230/460V AC
Bearing Type:
Ball
Exhaust/Supply Fan Motor HP:
3/4 hp
Motor Type:
3-Phase
Includes:
Hazardous Location Motor
Hazardous Location Class:
Class I, Div 1, Group C and D; Class II, Div 1, Group F and G
Standards:
AMCA, C-UL Listed, CSA, UL Listed
Venturi Depth:
4 in
Flange Width:
28 in
Maximum Inlet Temperature:
104 Degrees F
Overall Width:
28 in
Motor Speed:
1,750 RPM
Noise Level @ 0.125 in SP @ 5 ft:
27 sones
Duct Shape:
Not Applicable
Ventilation Type:
Exhaust
Method of Construction:
Stamped
Exhaust Airflow @ 0.000 in SP:
6,317 cfm
Manufacturer Warranty Length:
1 yr
Includes Dehumidistat:
No
Housing Finish:
Galvanized
Exhaust Airflow @ 0.125 in SP:
5,851 cfm
Overall Depth:
15 7/8 in
Exhaust Airflow @ 0.375 in SP:
4,729 cfm
Overall Height:
28 in
Number of Speeds:
1
Venturi Diameter:
24 1/2 in
Noise Level @ 0.000 in SP @ 5 ft:
28 sones
Speed Controllable:
No
Shaft Diameter:
5/8 in
Frequency:
60 Hz
Vent Design:
Ductless
Mounting Orientation:
Horizontal, Vertical
Duct Width:
Not Applicable
Fan Style:
Panel
Maximum Noise Level:
28 sones
For Cut-Out Length:
26 1/2 in
Blade Diameter:
24 in
Duct Diameter:
Not Applicable
Exhaust Airflow @ 0.250 in SP:
5,314 cfm
Exhaust Airflow @ 0.500 in SP:
4,117 cfm
Number of Fans:
1
Motor Horsepower:
3/4 hp
Maximum Ambient Operating Temperature:
104 Degrees F
Assembled:
Assembled
Duct Height:
Not Applicable
Maximum Airflow:
6,317 cfm
Nameplate Voltage:
208-230/460V AC
Includes Grill:
No
Guard Type:
None
Blade Material:
Aluminum
Housing Material:
Steel
For Cut-Out Width:
26 1/2 in
Full Load Current:
3.2 A
Includes Motor:
Yes
Wattage:
559 W
Drive Type:
Direct Drive
Voltage:
208-230/460
Package Quantity:
1
