Electronic Diagnostic Module, 22/30V DC, 24V DC, 288W, 12A, DIN Rail - 6EP1961-2BA11

Electronic Diagnostic Module, 22/30V DC, 24V DC, 288W, 12A, DIN Rail - 6EP1961-2BA11

Siemens
SKU:
6EP1961-2BA11
|
UPC:
40892692716
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Selectivity Module, For Use With Siemens SITOP Series DC Power Supplies, Mounting Type DIN Rail, Input Voltage 24V DC, Power Rating 288W, Voltage Output 24V DC, Amps 3 per Channel, Peak Amps 12 A, Status Indicator Green LED (Output Switched Through), Red LED (Output Switched Off Due to Overcurrent), Yellow LED (Output Switched Off Manually), Case Material Plastic, Height 3.14 in, Width 2.83 in, Depth 2.83 in, Temp. Range 32 to 140 Degrees F
Additional Information
Country of Origin:
Austria
Item:
Electronic Diagnostic Module
Input Voltage:
22/30V DC
Output Voltage:
24V DC
Power Rating:
288W
Output Amps:
12A
Mounting:
DIN Rail
Case Material:
Plastic Case
Height:
3.14 in
Width:
2.83 in
Depth:
2.83 in
Hz:
0 Hz
For Use With:
Siemens SITOP Series DC Power Supplies
Status Indicator:
Green LED (Output Switched Through), Red LED (Output Switched Off Due to Overcurrent), Yellow LED (Output Switched Off Manually)
Peak Amps:
12 A
Operating Temp. Range:
32 to 140°F
Standards:
CB Scheme, CE, cULus Listed (UL 508, CSA C22.2 No. 107.1) File E197259, EAC Approval, UL Listed, UL Recognized (UL 2367) File E328600
Protection:
Direct Voltage Overcurrent Protection
Output Current:
3 A
Connection:
Screw
Operating Temperature - Minimum:
-25 Degrees C
Compatible with Series:
SITOP
Housing Material:
Plastic
Operating Temperature - Maximum:
60 Degrees C
Package Quantity:
1
