Drum Pump, 110VAC, 1 HP, 60 Hz - 1DLP8

Drum Pump, 110VAC, 1 HP, 60 Hz - 1DLP8

Dayton
SKU:
1DLP8
|
UPC:
190735135341
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Electric Operated Drum Pump, Hose Inside Dia. 1 in, Max. Head Pressure 16 psi, Max. Oil Flow 7 gpm, Max. Outlet Pressure 16 psi, For Use With 9400, Rated Voltage 110V AC, Plug Type NEMA 5-15-P, Suction Tube OD 1 5/8 in, Hose Length 72 in, Suction Tube Length 39 in, Cord Length 16 ft, Includes Bung Adapter Yes, Runs Dry Yes, Nozzle Operation Manual, Thermal Protection Yes, Frequency (Hz) 50/60 Hz, Power Source Electric, Variable Speed Yes, Includes Discharge Hose Yes, Self-Priming Yes
Additional Information
Country of Origin:
United States
For Use With:
9400
Housing Material:
Polypropylene
Inlet Size:
1.6";Motor Type=Electric AC Brush"
Voltage:
110vac
Action Type:
Centrifugal
Max. Flow GPM:
32 gpm
Application:
For Transferring a Variety of Corrosive Liquids
Adapter Type:
Bung
Type:
Motor and Tube
DEF Compatible:
No
Suction Tube Length:
39 in
Metered:
No
Max. Pressure:
16 psi
Motor Enclosure:
ODP
Adapter Material:
Polypropylene
Discharge Tube Length:
6 ft.
RPM:
10,000
Pump Body Material:
Polypropylene
Outlet Size:
1 barb"
Max. Liquid Temp.:
130 Degrees F
Phase:
1
Item:
Electric Operated Drum Pump
Max. GPM for Water:
15
Self-Priming:
Yes
Overall Length:
51 in
Suction Tube Type:
Centrifugal
Max. Head:
36 ft.
Hz:
60
Max. Temp.:
130 Degrees F
Discharge Tubing Material:
PVC
Agency Compliance:
ETL Recognized Component(Motor Only)
Standards:
UL Recognized Component (Motor Only)
HP:
1
Max. GPM for Oil:
7
Adapter Dia.:
2";Wetted Materials=Carbon Graphite, Hastelloy C-276, Polypropylene, PVC, Viton"
GPM:
32
Max. Viscosity:
1,500 cps
Height:
39";Frequency (Hz)=50/60 Hz"
Max. Fluid Temp.:
130 Degrees F
Suction Tube OD:
1 5/8 in
Includes Bung Adapter:
Yes
Suction Tube Material:
Polypropylene
Includes Discharge Hose:
Yes
Power Source:
Electric
Noise Level:
84 db
Bung Connection Dia.:
2 in
For Container Size:
55 gal
Max. Flow Rate:
15 gpm
For Media Type:
Acetic Acid, Ammonia, Calcium Chloride, Chromic Acid, Citric Acid, Ethylene Glycol, Glycerin, Hydrochloric Acid, Hydrofluoric Acid, Nitric Acid, Phosphoric Acid (40% Solution), Potassium Hydroxide (50%), Sodium Bicarbonate, Sodium Bisulfate, Sodium B
Discharge Connection Type:
Hose Barb
Seal Material:
Sealless
Motor RPM:
0-10,000
Variable Speed:
Yes
Housing Material - Pumps:
Polypropylene
Discharge Tube Outlet ID:
1 in
Max. Head Pressure:
16 psi
Compatible Chemicals:
Acetic Acid 20%, Acetic Acid 80%, Ammonia (Liquids), Calcium Chloride, Chromic Acid 50%, Citric Acid 50%, Deionized Water, Ethylene Glycol, Fresh Water, Glycerin, Hydrochloric/Muriatic Acid (100%), Hydrochloric/Muriatic Acid (20%), Hydrochloric/Muria
Nozzle Material:
Polypropylene
Number of Phases:
1
Diesel Exhaust Fluid Compatible:
No
Food Grade:
No
Max. Oil Flow:
7 gpm
Spout Connection Type:
Hose Barb
Duty Cycle:
Intermittent
Hose Tube Material:
PVC
Discharge Tube Outlet OD:
1 1/2 in
Includes Suction Tube:
Yes
Full Load Amps:
8.5 A
Includes Nozzle:
Yes
Cord Length:
16 ft
Not Recommended Chemicals:
Acetic Acid (Glacial), Acetone, Ammonium Hydroxide, Chromic Acid 30%, Cyclohexane, DEF, Ethyl (Ethanol), Ethyl Acetate, Formaldehyde, Formaldehyde 40%, Formic Acid, Gasoline, Heptane, Hexane, Isopropyl (Isopropanol), Kerosene, Lacquer Thinners, Meth
Suction Tube ID:
1 3/8 in
Plug Type:
NEMA 5-15-P
Hose Outside Dia.:
1 1/4 in
Thermal Protection:
Yes
For Container Type:
Drum
Max. Head - Pumps:
36 ft
Motor HP:
1 1/10 hp
Includes Spout:
No
Nozzle Operation:
Manual
Hose Inside Dia.:
1 in
Hose Length:
72 in
Runs Dry:
Yes
Hose Cover Material:
PVC
Rated Voltage:
110V AC
Max. Outlet Pressure:
16 psi
Grease:
NT
Gear Lube:
NT
Adapter Connection Type:
MNPT
Package Quantity:
1
