Digital Panel Mount Thermometer - 3114200

Digital Panel Mount Thermometer - 3114200

Rittal
SKU:
3114200
|
UPC:
639889861183
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Panel Mount Thermometer, NTC Sensor Sensor Type, DIN Size 9/128, Output 10 A Relay Contact, 6 A Relay Contact, Control Mode Adjustable Selection, On/Off Action, Width 3 15/16 in, Depth 3 15/16 in, Alarms 2 Relay, SPDT, SPST, 6 A, Power Consumption 4 VA, Series Red Lion
Additional Information
Country of Origin:
Germany
Item:
Panel Mount Thermometer
Sensor Length:
1.8 m
Thermometer Power Source:
100 to 240V AC
Case Material:
Plastic
Temp. Range (F):
32 Degrees to 131 Degrees
Temp. Range (C):
5 Degrees to 55 Degrees
Accuracy:
+/- 2 K
Mounting:
DIN Rail
Depth:
3 15/16 in
Display Type:
Digital
Width:
3 15/16 in
Enclosure Rating:
IP54
Height:
2 35/64 in
Number of Digits:
3
Power Source Details:
100 to 230V AC
Sensor Technology:
NTC Thermistor
Temperature Scale:
Fahrenheit/Celsius
Digital Display:
3-Digit Display
Mounting Style:
DIN Rail
Maximum Temperature C:
55 Degrees C
Voltage:
100 to 230V
Minimum Temperature C:
5 Degrees C
Includes Batteries:
Yes
Thermometer Type:
Panel-Mount Digital Thermometer
Scale Type:
Digital
Cable Length:
1.8 m
Probe Technology:
NTC Thermistor - Probe
Temperature Range:
5 Degrees to 55 Degrees C
Process Connection:
1.8 m Cable
Minimum Temperature °C:
5 Degrees C
Maximum Temperature °C:
55 Degrees C
Output:
10 A Relay Contact, 6 A Relay Contact
Temperature - Minimum:
0 Degrees C
Control Mode:
Adjustable Selection, On/Off Action
Overall Height:
39 mm
Alarms:
2 Relay, SPDT, SPST, 6 A
Control Period - Minimum:
Not Applicable
Overall Width:
98 mm
Current:
100 mA
Control Period - Maximum:
Not Applicable
Series:
Red Lion
Power Consumption:
4 VA
DIN Size:
9/128
Overall Length:
74 1/2 mm
Temperature - Maximum:
50 Degrees C
Sensor Type:
NTC Sensor
Product Type:
Panel Mount Thermometer
Package Quantity:
1
