DC Gearmotor, 9 rpm, 12V, TENV - 1LPV7
DC Gearmotor, Shaft Orientation Parallel, Motor Enclosure Totally Enclosed Nonventilated, Operating Voltage 12V DC, Motor Type Permanent Magnet DC, Nameplate Speed 9 RPM, Maximum Torque 50 in-lb, Overhung Load Capacity 50 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Gear Ratio 273:1, Input Horsepower 1/30 hp, Output Shaft Diameter 5/16 in, Bearing Type Ball on Motor, Porous Bronze Sleeve on Case
- Country of Origin:
- United States
- Gearmotor Type:
- DC Gearmotor
- Gearmotor Voltage:
- 12V DC
- Max. Torque:
- 50 in-lb
- Gearmotor Shaft Type:
- Single
- Gearmotor Shaft Orientation:
- Parallel
- Rear Shaft Encoder/Pulse Generator Mounting:
- No
- Nameplate RPM:
- 9 RPM
- Gearmotor Enclosure:
- Totally Enclosed Nonventilated
- Gearmotor Mounting Position:
- All Angle
- Gearmotor Rotation:
- CW/CCW
- Length Less Shaft:
- 6.13 in
- Item:
- DC Gearmotor
- Overhung Load:
- 50 lb
- Motor Type:
- Permanent Magnet DC
- Overall Length:
- 6.88 in
- Standards:
- C-UL Recognized, UL Recognized
- Max. Ambient Temp.:
- 40 Degrees C
- Gear Material:
- Acetyl, Steel
- Input HP:
- 1/30
- Shaft:
- Single Output
- Shaft Length (Dimension V):
- 3/4 in
- Dimension A:
- 6.2 in
- RPM Range:
- 0 to 15
- Voltage:
- 12VDC
- Brushes:
- Externally Replaceable
- Replacement Brushes:
- 6YHY4
- Housing Material:
- Die Cast Zinc
- Finish:
- Unpainted
- Seals:
- O-ring Type on Output Shaft
- Gear Ratio:
- 273
- Mounting:
- All Position
- Gear Case:
- Die Cast Zinc
- Tachometer Feedback:
- No
- Reversible Shaft Output:
- No
- Bearings:
- Ball on Motor, Porous Bronze Sleeve on Case
- Keyway Size Type:
- Flat
- Shaft Dia. (Dimension U):
- 5/16";Rotation=CW/CCW"
- Shaft Orientation:
- Parallel
- Full Load Amps:
- 2.1 A
- Enclosure:
- TENV
- Thermal Protection:
- None
- Lubrication:
- Grease Filled
- Keyway Size:
- Flat
- Insulation Class:
- F
- Keyway Type:
- Flat
- Input Horsepower:
- 1/30 hp
- Maximum Ambient Temperature:
- 40 Degrees C
- Seal Type:
- O-Ring Type on Output Shaft
- Overhung Load Capacity:
- 50 ft-lb
- Operating Voltage:
- 12V DC
- Housing Material Finish:
- Unpainted
- Motor Enclosure:
- Totally Enclosed Nonventilated
- Output Shaft Length:
- 3/4 in
- Mounting Orientation:
- Any Angle
- Nameplate Speed:
- 9 RPM
- Full Load Current:
- 2.1 A
- Maximum Torque:
- 50 in-lb
- Output Shaft Diameter:
- 5/16 in
- Replaceable Motor Brushes:
- Yes
- Bearing Type:
- Ball on Motor, Porous Bronze Sleeve on Case
- Package Quantity:
- 1
