DC Gearmotor, 50.0 in-lb Max. Torque, 6 RPM Nameplate RPM, 12V DC Voltage - 1LPV8

DC Gearmotor, 50.0 in-lb Max. Torque, 6 RPM Nameplate RPM, 12V DC Voltage - 1LPV8

Dayton
SKU:
1LPV8
|
UPC:
190735144381
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
DC Gearmotor, Shaft Orientation Parallel, Motor Enclosure Totally Enclosed Nonventilated, Operating Voltage 12V DC, Motor Type Permanent Magnet DC, Nameplate Speed 6 RPM, Maximum Torque 50 in-lb, Overhung Load Capacity 50 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Gear Ratio 430:1, Input Horsepower 1/30 hp, Output Shaft Diameter 5/16 in, Bearing Type Ball on Motor, Porous Bronze Sleeve on Case
Additional Information
Country of Origin:
United States
Item:
DC Gearmotor
Gearmotor Voltage:
12V DC
Gearmotor Type:
DC Gearmotor
Max. Torque:
50 in-lb
Gearmotor Shaft Type:
Single
Gearmotor Shaft Orientation:
Parallel
Nameplate RPM:
6 RPM
Gearmotor Enclosure:
Totally Enclosed Nonventilated
Gearmotor Rotation:
CW/CCW
Length Less Shaft:
6.13 in
Gearmotor Mounting Position:
All Angle
Full Load Amps:
2.1 A
Keyway Size Type:
Flat
Standards:
C-UL Recognized, UL Recognized
Input HP:
1/30
Finish:
Unpainted
Keyway Size:
Flat
Enclosure:
TENV
Shaft Length (Dimension V):
3/4 in
Motor Type:
Permanent Magnet DC
Max. Ambient Temp.:
40 Degrees C
Lubrication:
Grease Filled
Shaft:
Single Output
Housing Material:
Die Cast Zinc
Gear Ratio:
430
Gear Material:
Acetyl, Steel
Bearings:
Ball on Motor, Porous Bronze Sleeve on Case
Seals:
O-ring Type on Output Shaft
Voltage:
12VDC
Rear Shaft Encoder/Pulse Generator Mounting:
No
Thermal Protection:
None
Overall Length:
6.88 in
Reversible Shaft Output:
No
Rotation:
CW/CCW
Shaft Orientation:
Parallel
Overhung Load:
50 lb
Gear Case:
Die Cast Zinc
Tachometer Feedback:
No
Dimension A:
6.2 in
Replacement Brushes:
6YHY4
Shaft Dia. (Dimension U):
5/16";Mounting=All Position"
Insulation Class:
F
Brushes:
Externally Replaceable
RPM Range:
0 to 15
Operating Voltage:
12V DC
Replaceable Motor Brushes:
Yes
Keyway Type:
Flat
Output Shaft Diameter:
5/16 in
Output Shaft Length:
3/4 in
Maximum Torque:
50 in-lb
Full Load Current:
2.1 A
Maximum Ambient Temperature:
40 Degrees C
Input Horsepower:
1/30 hp
Bearing Type:
Ball on Motor, Porous Bronze Sleeve on Case
Overhung Load Capacity:
50 ft-lb
Mounting Orientation:
Any Angle
Housing Material Finish:
Unpainted
Nameplate Speed:
6 RPM
Motor Enclosure:
Totally Enclosed Nonventilated
Seal Type:
O-Ring Type on Output Shaft
Package Quantity:
1
