Current Sensing Relay, 1.5A, Self Powered - ECSNOFSP

Current Sensing Relay, 1.5A, Self Powered - ECSNOFSP

Eaton
SKU:
ECSNOFSP
|
UPC:
786685120942
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Current Sensor Relay, Contact Form SPST-NO, Contact Rating (AC) 0.15 A @ 240V, Contact Rating (DC) 0.15 A @ 240V, Core Type Split, Current Rating 150 A, Input Voltage Not Applicable, Monitored Parameters Overcurrent, Undercurrent, Mounting Style Surface, Number of Pins 2, Trip Point 1.50 A, Trip Point Type Fixed, Adjustment Method Switch, Electrical Connection Screw Terminal, Sensing Hole Diameter 0.85 in, Status Indicator No Indicator, Wire Gauge 14 AWG, Body Depth 4 in, Body Height 2 in
Additional Information
Country of Origin:
United States
Item - Relay:
Current Sensing Relay
Input or Control Voltage:
Self Powered
AC Contact Rating - Relay:
0.15A @ 240V
DC Contact Rating - Relay:
0.15A @ 240V
Mounting - Relay:
Surface
Contact Form - Relay:
SPST-NO
Sensing Amp Range:
1.75 to 150.00A
Trip Point:
1.50 A
Trip Delay:
0.12 sec
Core Type - Relay:
Split
Body Height - Relay:
2.25 in
Contact Amps:
0.15A
Overall Height - Relay:
2.5 in
Electrical Connection:
Screw Terminal
Input Voltage:
Not Applicable
Status Indicator:
No Indicator
Sensor Opening:
0.85 in
Body Width - Relay:
3.53 in
Type of Output:
Solid State
Item:
Current Sensor Relay
Mounting:
Surface
Max. Inrush Current:
1.5 A
Core Type:
Split
Contact Form:
SPST-NO
Body Depth - Relay:
1.19 in
Maximum Operating Temperature:
122 Degrees F
Wire Gauge:
14 AWG
Current Rating:
150 A
Housing Material:
Plastic
Mounting Style:
Surface
Monitored Parameters:
Overcurrent, Undercurrent
Contact Rating (AC):
0.15 A @ 240V
Weight:
1 lb
Minimum Operating Temperature:
-58 Degrees F
Adjustment Method:
Switch
Body Depth:
4 in
Body Height:
2 in
Body Width:
3.5 in
Trip Point Type:
Fixed
Contact Rating (DC):
0.15 A @ 240V
Overall Depth:
2.25 in
For Use With:
Sensors
Number of Pins:
2
Standards:
RoHS Compliant, UL Listed
Frequency:
100 Hz
Sensing Hole Diameter:
0.85 in
Operating Current:
0.5 A, 150 A
LED indicator:
None
AC current - max:
150 A monitor, 0.15 A switch
Switch type:
Current switch
Connection:
Screw terminal
Product Width:
1.19 in
Contact configuration:
Isolated solid state relay
Enclosure material:
UL94 V0 flammability rated plastic
Operating Temperature:
-58° to 122°F (-50° to 50°C)
Product Height:
3.53 in
Product Length/Depth:
2.25 in
Contact Rating:
0.15A at 240V AC/DC
Product Name:
Eaton ECS series CurrentWatch AC current switch
Package Quantity:
1
