Current Sens Rly, 1.75to150A, Self Powered - ECSNOASP

Current Sens Rly, 1.75to150A, Self Powered - ECSNOASP

Eaton
SKU:
ECSNOASP
|
UPC:
786685120935
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Adjustable Current Sensing Relay, Contact Form SPST-NO, Contact Rating (AC) 0.15 A @ 240V, Contact Rating (DC) 0.15 A @ 240V, Core Type Split, Current Rating 150 A, Input Voltage Not Applicable, Monitored Parameters Overcurrent, Undercurrent, Mounting Style Surface, Number of Pins 2, Trip Point 1.75 to 150 A, Trip Point Type Adjustable, Adjustment Method Switch, Electrical Connection Screw Terminal, Sensing Hole Diameter 0.85 in, Status Indicator LED Indicator, Wire Gauge 14 AWG
Additional Information
Country of Origin:
United States
Item - Relay:
Current Sensing Relay
Input or Control Voltage:
Self Powered
AC Contact Rating - Relay:
0.15A @ 240V
DC Contact Rating - Relay:
0.15A @ 240V
Mounting - Relay:
Surface
Contact Form - Relay:
SPST-NO
Sensing Amp Range:
1.75 to 150.00A
Trip Point:
1.75 to 150 A
Trip Delay:
0.12 sec
Core Type - Relay:
Split
Contact Form:
SPST-NO
Body Height - Relay:
2.25 in
Type of Output:
Solid State
Input Voltage:
Not Applicable
Body Depth - Relay:
1.19 in
Electrical Connection:
Screw Terminal
Contact Amps:
0.15A
Item:
Adjustable Current Sensing Relay
Sensor Opening:
0.85 in
Body Width - Relay:
3.53 in
Overall Height - Relay:
2.5 in
Mounting:
Surface
Core Type:
Split
Status Indicator:
LED Indicator
Max. Inrush Current:
150 A
For Use With:
Sensors
Weight:
0.33 lb
Operating Current:
150 A
Maximum Operating Temperature:
122 Degrees F
Body Width:
1.19 in
Contact Rating (AC):
0.15 A @ 240V
Minimum Operating Temperature:
-58 Degrees F
Standards:
RoHS Compliant, UL Listed
Mounting Style:
Surface
Overall Depth:
2.25 in
Frequency:
100 Hz
Number of Pins:
2
Trip Point Type:
Adjustable
Monitored Parameters:
Overcurrent, Undercurrent
Wire Gauge:
14 AWG
Current Rating:
150 A
Housing Material:
Plastic
Adjustment Method:
Switch
Sensing Hole Diameter:
0.85 in
Body Depth:
3.53 in
Body Height:
2.25 in
Contact Rating (DC):
0.15 A @ 240V
Product Width:
1.19 in
Contact Rating:
0.15A at 240 Vac/dc
Connection:
Screw terminal
Operating Temperature:
-58° to 122°F
Enclosure material:
UL94 V0 flammability rated plastic
Product Length/Depth:
3.53 in
Contact configuration:
SSR
AC current - max:
150 A
LED indicator:
LED indicator
Switch type:
Adjustable 1.75-150 A setpoint
Product Height:
2.25 in
Product Name:
Eaton ECS series CurrentWatch AC current switch
Package Quantity:
1
