Coupling, Two Piece, Bore Dia 40 mm - MSPX-40-40-SS

Coupling, Two Piece, Bore Dia 40 mm - MSPX-40-40-SS

Ruland
SKU:
MSPX-40-40-SS
|
UPC:
634529018392
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Rigid Shaft Coupling, Bore Diameter 1 40 mm, Bore Diameter 2 40 mm, Bore Type Round, Clearance Diameter 84 mm, Coupling Construction Two-Piece, Coupling Material Stainless Steel, Coupling Outside Diameter 77 mm, Different Bore Sizes No, Keyway Depth 1 Not Applicable, Keyway Depth 2 Not Applicable, Minimum Bore Diameter 40 mm, Keyway Width 1 Not Applicable, Keyway Width 2 Not Applicable, Maximum Bore Diameter 40 mm, Maximum Speed 4,000 RPM, Maximum Torque 400 N-m, Overall Length 108 mm
Additional Information
Country of Origin:
United States
Item:
Rigid Shaft Coupling
Shaft Locking Type - Couplings:
2 Piece Clamp
System of Measurement:
Metric
Bore Dia.:
40 mm
Material - Couplings:
Stainless Steel
Outside Dia.:
77 mm
Overall Length:
108 mm
With Keyway / Without Keyway:
Without Keyway
Finish:
Bright
Max. Torque (In.-Lbs.):
9400
Item - Rigid Shaft Couplings:
Rigid Shaft Coupling
Clearance Dia.:
84.0 mm
Application:
For Applications where Alignment is Critical, Particularly when no Backlash is Desired and Flexibility is not Required, Useful when Timing, Joining and/or Aligning Shafts at Lower Speeds and Torque
Clearance Dia. (mm):
84.00
Material:
Stainless Steel
Type:
Two Piece Clamp Type, Without Keyway
Screw Size:
M8
Machined From:
Bar Stock
Screw Size (mm):
M8
Max. Torque:
9,400 in-lb
Design:
Four Vibration Resistant Socket Capscrews
Provides:
Extra Holding Power for Higher Load Applications without Marring Shafts
Standards:
Conflict Minerals Compliant, DIN 912 12.9 Screws, REACH Compliant, RoHS3 Compliant
Screw Material:
Stainless Steel
Bore Tolerance:
+0.050 mm / +0.012 mm
Different Bore Sizes:
No
Resistance Properties:
Corrosion Resistant
Maximum Speed:
4,000 RPM
Recommended Gap:
2.38 mm
Maximum Operating Temperature:
176 Degrees C
Screw Location from Center:
31.8 mm
Minimum Operating Temperature:
-40 Degrees C
Fastener Tightening Torque:
23 N-m
Maximum Torque:
400 N-m
Screw Material Grade:
18-8 300 Series
Coupling Outside Diameter:
77 mm
Keyway Width 1:
Not Applicable
Bore Diameter 1:
40 mm
Features:
Precision Honed Bores, Vibration-Resistant Screws
Screw Material Finish:
Bright
Coupling Material Grade:
303
Keyway Depth 2:
Not Applicable
Zero Backlash:
Yes
Keyway Depth 1:
Not Applicable
Minimum Bore Diameter:
40 mm
Number of Locking Screws:
8
Coupling Material Finish:
Bright
Shaft Locking Type:
Clamp On
Keyway Width 2:
Not Applicable
Screw Thread Size:
M8
Shaft Tolerance:
+0.000 mm / -0.013 mm
Included Screws:
(8) Clamp Screws
Clearance Diameter:
84 mm
Coupling Construction:
Two-Piece
Bore Diameter 2:
40 mm
Bore Type:
Round
Maximum Bore Diameter:
40 mm
Coupling Material:
Stainless Steel
Package Quantity:
1
