Coupling, Two Piece, Bore Dia 1/4 In - SPX-4-4-SS

Coupling, Two Piece, Bore Dia 1/4 In - SPX-4-4-SS

Ruland
SKU:
SPX-4-4-SS
|
UPC:
634529026403
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Rigid Shaft Coupling, Bore Diameter 1 1/4 in, Bore Diameter 2 1/4 in, Bore Type Round, Clearance Diameter 0.82 in, Coupling Construction Two-Piece, Coupling Material Stainless Steel, Coupling Outside Diameter 5/8 in, Different Bore Sizes No, Keyway Depth 1 Not Applicable, Keyway Depth 2 Not Applicable, Minimum Bore Diameter 1/4 in, Keyway Width 1 Not Applicable, Keyway Width 2 Not Applicable, Maximum Bore Diameter 1/4 in, Maximum Speed 4,000 RPM, Maximum Torque 60 in-lb, Overall Length 1 in
Additional Information
Country of Origin:
United States
Item:
Rigid Shaft Coupling
Shaft Locking Type - Couplings:
2 Piece Clamp
System of Measurement:
Inch
Bore Dia.:
1/4 in
Material - Couplings:
Stainless Steel
Outside Dia.:
5/8 in
Overall Length:
1 in
With Keyway / Without Keyway:
Without Keyway
Finish:
Bright
Design:
Four Vibration Resistant Socket Capscrews
Standards:
ANSI, Conflict Minerals Compliant, REACH Compliant, RoHS3 Compliant
Screw Size (In.):
#4-40
Application:
For Applications where Alignment is Critical, Particularly when no Backlash is Desired and Flexibility is not Required, Useful when Timing, Joining and/or Aligning Shafts at Lower Speeds and Torque
Material:
Stainless Steel
Machined From:
Bar Stock
Type:
Two Piece Clamp Type, Without Keyway
Clearance Dia.:
0.815 in
Item - Rigid Shaft Couplings:
Rigid Shaft Coupling
Max. Torque:
60 in-lb
Clearance Dia. (In.):
0.815
Screw Size:
#4-40
Max. Torque (In.-Lbs.):
60
Provides:
Extra Holding Power for Higher Load Applications without Marring Shafts
Screw Material:
Stainless Steel
Bore Tolerance:
+0.0020 in / +0.0005 in
Bore Type:
Round
Maximum Speed:
4,000 RPM
Resistance Properties:
Corrosion Resistant
Number of Locking Screws:
8
Coupling Outside Diameter:
5/8 in
Screw Thread Size:
#4-40
Keyway Depth 1:
Not Applicable
Keyway Depth 2:
Not Applicable
Coupling Construction:
Two-Piece
Maximum Bore Diameter:
1/4 in
Minimum Bore Diameter:
1/4 in
Features:
Precision Honed Bores, Vibration-Resistant Screws
Fastener Tightening Torque:
8 lb-in
Minimum Operating Temperature:
-40 Degrees F
Recommended Gap:
0.047 in
Maximum Operating Temperature:
350 Degrees F
Clearance Diameter:
0.82 in
Screw Material Grade:
18-8 300 Series
Included Screws:
(8) Clamp Screws
Keyway Width 1:
Not Applicable
Coupling Material Finish:
Bright
Bore Diameter 1:
1/4 in
Bore Diameter 2:
1/4 in
Different Bore Sizes:
No
Shaft Locking Type:
Clamp On
Coupling Material:
Stainless Steel
Maximum Torque:
60 in-lb
Screw Material Finish:
Bright
Keyway Width 2:
Not Applicable
Coupling Material Grade:
303
Shaft Tolerance:
+0.0000 in / -0.0005 in
Screw Location from Center:
0.219 in
Zero Backlash:
Yes
Package Quantity:
1
