Coupling, One Piece, Bore Dia 30 mm - MCLC-30-30-SS

Coupling, One Piece, Bore Dia 30 mm - MCLC-30-30-SS

Ruland
SKU:
MCLC-30-30-SS
|
UPC:
634529013175
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Rigid Shaft Coupling, Bore Diameter 1 30 mm, Bore Diameter 2 30 mm, Bore Type Round Keyed, Clearance Diameter 58.7 mm, Coupling Construction One-Piece, Coupling Material Stainless Steel, Coupling Outside Diameter 53 mm, Different Bore Sizes No, Keyway Depth 1 3.5 mm, Keyway Depth 2 3.5 mm, Minimum Bore Diameter 30 mm, Keyway Width 1 8 mm, Keyway Width 2 8 mm, Maximum Bore Diameter 30 mm, Maximum Speed 4,000 RPM, Maximum Torque 150 N-m, Overall Length 83 mm, Shaft Locking Type Clamp On
Additional Information
Country of Origin:
United States
Item:
Rigid Shaft Coupling
Shaft Locking Type - Couplings:
1 Piece Clamp
System of Measurement:
Metric
Bore Dia.:
30 mm
Material - Couplings:
303 Stainless Steel
Outside Dia.:
53 mm
Overall Length:
83 mm
With Keyway / Without Keyway:
With Keyway
Finish:
Bright
Clearance Dia. (mm):
58.70
Application:
For Applications where Alignment is Critical, Particularly when no Backlash is Desired and Flexibility is not Required, Useful when Timing, Joining and/or Aligning Shafts at Lower Speeds and Torque
Machined From:
Bar Stock
Item - Rigid Shaft Couplings:
Rigid Shaft Coupling
Max. Torque (In.-Lbs.):
3600
Screw Size (mm):
M6
Material:
303 Stainless Steel
Design:
Four Vibration Resistant Socket Capscrews
Type:
One Piece Clamp Type, with Keyway
Max. Torque:
3,600 in-lb
Screw Size:
M6
Keyway Width (mm):
8
Keyway Width:
8 mm
Provides:
Extra Holding Power for Higher Load Applications without Marring Shafts
Clearance Dia.:
58.7 mm
Standards:
Conflict Minerals Compliant, DIN 912 12.9 Screws, REACH Compliant, RoHS3 Compliant
Bore Tolerance:
+0.050 mm / +0.012 mm
Screw Material:
Stainless Steel
Maximum Speed:
4,000 RPM
Clearance Diameter:
58.7 mm
Coupling Material Grade:
303
Screw Material Grade:
18-8 300 Series
Maximum Torque:
150 N-m
Keyway Depth 1:
3.5 mm
Different Bore Sizes:
No
Screw Material Finish:
Bright
Bore Type:
Round Keyed
Coupling Material Finish:
Bright
Keyway Width 2:
8 mm
Features:
Precision Honed Bores, Vibration-Resistant Screws
Included Screws:
(4) Clamp Screws
Keyway Depth 2:
3.5 mm
Shaft Tolerance:
+0.000 mm / -0.013 mm
Screw Thread Size:
M6
Minimum Operating Temperature:
-40 Degrees C
Zero Backlash:
Yes
Bore Diameter 2:
30 mm
Shaft Locking Type:
Clamp On
Maximum Bore Diameter:
30 mm
Resistance Properties:
Corrosion Resistant
Maximum Operating Temperature:
176 Degrees C
Coupling Construction:
One-Piece
Fastener Tightening Torque:
9.6 N-m
Recommended Gap:
Not Applicable
Keyway Width 1:
8 mm
Coupling Material:
Stainless Steel
Number of Locking Screws:
4
Minimum Bore Diameter:
30 mm
Bore Diameter 1:
30 mm
Screw Location from Center:
20.9 mm
Coupling Outside Diameter:
53 mm
Package Quantity:
1
