Coupling, One Piece, Bore Dia 25 mm - MCLX-25-25-F

Coupling, One Piece, Bore Dia 25 mm - MCLX-25-25-F

Ruland
SKU:
MCLX-25-25-F
|
UPC:
634529014103
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Rigid Shaft Coupling, Bore Diameter 1 25 mm, Bore Diameter 2 25 mm, Bore Type Round, Clearance Diameter 51.5 mm, Coupling Construction One-Piece, Coupling Material Carbon Steel, Coupling Outside Diameter 45 mm, Different Bore Sizes No, Keyway Depth 1 Not Applicable, Keyway Depth 2 Not Applicable, Minimum Bore Diameter 25 mm, Keyway Width 1 Not Applicable, Keyway Width 2 Not Applicable, Maximum Bore Diameter 25 mm, Maximum Speed 4,000 RPM, Maximum Torque 400 N-m, Overall Length 75 mm
Additional Information
Country of Origin:
United States
Item:
Rigid Shaft Coupling
Shaft Locking Type - Couplings:
1 Piece Clamp
System of Measurement:
Metric
Bore Dia.:
25 mm
Material - Couplings:
1215 Lead Free Steel
Outside Dia.:
45 mm
Overall Length:
75 mm
With Keyway / Without Keyway:
Without Keyway
Finish:
black oxide
Application:
For Applications where Alignment is Critical, Particularly when no Backlash is Desired and Flexibility is not Required, Useful when Timing, Joining and/or Aligning Shafts at Lower Speeds and Torque
Type:
One Piece Clamp Type, Without Keyway
Machined From:
Bar Stock
Clearance Dia.:
51.5 mm
Clearance Dia. (mm):
51.50
Screw Size:
M6
Max. Torque (In.-Lbs.):
3450
Max. Torque:
3,450 in-lb
Item - Rigid Shaft Couplings:
Rigid Shaft Coupling
Provides:
Extra Holding Power for Higher Load Applications without Marring Shafts
Material:
Black Oxide 1215 Lead Free Steel
Design:
Four Vibration Resistant Socket Capscrews
Screw Size (mm):
M6
Standards:
Conflict Minerals Compliant, DIN 912 12.9 Screws, REACH Compliant, RoHS3 Compliant
Screw Material:
Alloy Steel
Bore Tolerance:
+0.050 mm / +0.012 mm
Minimum Bore Diameter:
25 mm
Screw Location from Center:
16.9 mm
Maximum Torque:
400 N-m
Keyway Depth 1:
Not Applicable
Coupling Construction:
One-Piece
Included Screws:
(4) Clamp Screws
Recommended Gap:
Not Applicable
Maximum Bore Diameter:
25 mm
Different Bore Sizes:
No
Keyway Depth 2:
Not Applicable
Coupling Material Finish:
Black Oxide
Resistance Properties:
Corrosion Resistant
Screw Material Finish:
Black Oxide
Coupling Material Grade:
1215
Bore Type:
Round
Features:
Precision Honed Bores, Vibration-Resistant Screws
Shaft Tolerance:
+0.000 mm / -0.013 mm
Coupling Material:
Carbon Steel
Bore Diameter 2:
25 mm
Shaft Locking Type:
Clamp On
Maximum Speed:
4,000 RPM
Keyway Width 2:
Not Applicable
Screw Thread Size:
M6
Maximum Operating Temperature:
176 Degrees C
Zero Backlash:
Yes
Fastener Tightening Torque:
16 N-m
Keyway Width 1:
Not Applicable
Clearance Diameter:
51.5 mm
Minimum Operating Temperature:
-40 Degrees C
Coupling Outside Diameter:
45 mm
Bore Diameter 1:
25 mm
Number of Locking Screws:
4
Package Quantity:
1
