Coupling, Double Disc, Bore 5/16x5/16 In - DCD16-5-5-A

Coupling, Double Disc, Bore 5/16x5/16 In - DCD16-5-5-A

Ruland
SKU:
DCD16-5-5-A
|
UPC:
634529081624
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Motion Control Coupling, Angular Misalignment 2 Degrees , Axial Motion 0.012 in, Bore Diameter 1 5/16 in, Bore Diameter 2 5/16 in, Bore Type Round, Dynamic Torque Non-Reversing 25 lb-in, Hub Length 0.5 in, Hub Material Aluminum, Dynamic Torque Reversing 12.5 lb-in, Coupling Outside Diameter 1 in, Number of Discs 2 with Center Spacer, Center Spacer Material Aluminum, Length Through Bore 1 0.7 in, Length Through Bore 2 0.7 in, Maximum Bore Diameter 5/16 in, Minimum Bore Diameter 5/16 in
Additional Information
Country of Origin:
United States
Shaft Locking Type - Couplings:
1 Piece Clamp
Bore Dia.:
5/16 in x 5/16 in
Rated Torque:
50 in-lb
Max. RPM:
10,000 RPM
Outside Dia.:
1 in
Overall Length:
1 3/8 in
Material - Couplings:
Aluminum
Max. Temp.:
200 Degrees F
Finish:
Anodized Aluminum
Screw Size:
M3
Max. Parallel Misalignment (In.):
0.006 in
Disc Type:
Stainless Steel
Max. Temp. Range (F):
200
Screw Type:
Cap Screw
Material:
Aluminum
Item:
Motion Control Coupling
Length through Bore (In.):
0.688
Torsional Stiffness (Deg./In.-Lbs.):
0.011
Screw Size (mm):
M3
Outside Dia. (In.):
1.000
Overall Length (In.):
1.375
Style:
Double Disc Clamp
Length through Bore:
0.688 in
Max. Axial Misalignment (In.):
+/-0.012
Item - Motion Control Couplings:
Motion Control Coupling
Clearance Dia. (In.):
1.0 in
Max. Angular Misalignment:
2 Degrees
Torque (In.-Lbs.):
50
Dynamic Torque Non-Reversing:
25 lb-in
Moment of Inertia:
0.0117 lb-in sq
Axial Motion:
0.012 in
Bore Tolerance:
+0.001 in / -0.000 in
Dynamic Torque Reversing:
12.5 lb-in
Screw Material:
Alloy Steel
Bore Type:
Round
Hub Material Grade:
2024
Full Bearing Support Required:
Yes
Coupling Outside Diameter:
1 in
Features:
Balanced Design for Reduced Vibration, Disc Spring Sets Bend Independent of Each Other, Lightweight and has Low Inertia
Angular Misalignment:
2 Degrees
Screw Thread Size:
M3
Parallel Misalignment:
0.006 in
For Misalignment Type:
Angular, Axial, Parallel
Number of Locking Screws:
2
System of Measurement:
Inch
Minimum Bore Diameter:
5/16 in
Hub Material Finish:
Anodized Aluminum
Different Bore Sizes:
No
Hub Material:
Aluminum
Application:
Precise Positioning Stepper Servo
Disc Material:
Stainless Steel
Standards:
Conflict Minerals Compliant, DIN 912 12.9 Screws, REACH Compliant, RoHS Compliant
Screw Material Finish:
Black Oxide
Maximum Operating Temperature:
200 Degrees F
Shaft Tolerance:
+0.0000/-0.0005 in
Torsional Stiffness:
61 in-lb/Deg
Maximum Speed:
10,000 RPM
Number of Discs:
2 with Center Spacer
Disc Material Finish:
Black Anodized
Hub Length:
0.5 in
Length Through Bore 2:
0.7 in
Maximum Bore Diameter:
5/16 in
Length Through Bore 1:
0.7 in
Maximum Torque:
50 in-lb
Zero Backlash:
Yes
Included Screws:
(2) Hex Socket Cap Screw
Bore Diameter 2:
5/16 in
Minimum Operating Temperature:
-10 Degrees F
For Environment:
Angular Misalignment, Axial Motion, Parallel Misalignment
Bore Diameter 1:
5/16 in
Fastener Tightening Torque:
2.1 N-m
Center Spacer Material:
Aluminum
Disc Material Grade:
302
Shaft Locking Type:
Clamp On
Package Quantity:
1
