Coupling, 6 Beam Clamp, Bore 1/2 x 1/2 In - FCR24-8-8-SS

Coupling, 6 Beam Clamp, Bore 1/2 x 1/2 In - FCR24-8-8-SS

Ruland
SKU:
FCR24-8-8-SS
|
UPC:
634529051726
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Motion Control Coupling, Angular Misalignment 3 Degrees , Bore Diameter 1 1/2 in, Bore Diameter 2 1/2 in, Coupling Material Stainless Steel, Coupling Outside Diameter 1 1/2 in, Maximum Speed 6,000 RPM, Maximum Torque 190 in-lb, Axial Motion 0.015 in, Overall Length 2 1/4 in, Parallel Misalignment 0.03 in, System of Measurement Inch, Different Bore Sizes No, Torsional Stiffness 47.62 in-lb/Deg, Bore Type Round, Shaft Locking Type Clamp On, Number of Beams 6, Length Through Bore 2 1.1 in
Additional Information
Country of Origin:
United States
Shaft Locking Type - Couplings:
1 Piece Clamp
Bore Dia.:
1/2 in x 1/2 in
Rated Torque:
190 in-lb
Max. RPM:
6,000 RPM
Outside Dia.:
1.5 in
Overall Length:
2 1/4 in
Material - Couplings:
Stainless Steel
Length through Bore (In.):
1.125
Max. Temp.:
350 Degrees F
Overall Length (In.):
2.25
Screw Type:
Cap Screw
Screw Size (mm):
M6
Clearance Dia. (In.):
1.642 in
Style:
6 Beam Clamp
Max. Parallel Misalignment (In.):
0.03 in
Max. Temp. Range (F):
350
Max. Axial Misalignment (In.):
+/-0.015
Item:
Motion Control Coupling
Screw Size:
M6
Torque (In.-Lbs.):
190
Outside Dia. (In.):
1.500
Item - Motion Control Couplings:
Motion Control Coupling
Max. Angular Misalignment:
3 Degrees
Finish:
Bright
Length through Bore:
1.125 in
Material:
Stainless Steel
Torsional Stiffness (Deg./In.-Lbs.):
0.021
Bore Tolerance:
+0.001/-0.000 in
Axial Motion:
0.015 in
Screw Material:
Alloy Steel with Nypatch
Moment of Inertia:
0.2814 lb-in sq
Dynamic Torque Reversing:
47.5 lb-in
Dynamic Torque Non-Reversing:
95 lb-in
Number of Locking Screws:
2
Standards:
Conflict Minerals Compliant, DIN 912 12.9 Screws, REACH Compliant, RoHS Compliant
Coupling Material Grade:
303
For Environment:
Angular Misalignment, Axial Motion, Parallel Misalignment
Torsional Stiffness:
47.62 in-lb/Deg
Screw Thread Size:
M6
Screw Material Finish:
Black Oxide
Parallel Misalignment:
0.03 in
Application:
Light-Duty Power Transmission, Servo Motors to Lead Screws
Shaft Tolerance:
+0.0000/-0.0005 in
Fastener Tightening Torque:
16 N-m
Maximum Torque:
190 in-lb
Full Bearing Support Required:
Yes
Coupling Material Finish:
Bright
Different Bore Sizes:
No
Minimum Operating Temperature:
-40 Degrees F
Angular Misalignment:
3 Degrees
Length Through Bore 2:
1.1 in
Maximum Speed:
6,000 RPM
System of Measurement:
Inch
Included Screws:
(2) Hex Socket Cap Screw
Length Through Bore 1:
1.1 in
Bore Diameter 2:
1/2 in
Maximum Operating Temperature:
350 Degrees F
Features:
Balanced Design for Reduced Vibration, Higher Torque Capacity, Larger Body Sizes than Single or Four Beam Couplings, Lower Windup, Machined from a Single Piece of Material, Spiral Coupling With Nypatch Anti-Vibration Hardware, Two Sets of Three Spira
Zero Backlash:
Yes
For Misalignment Type:
Angular, Axial, Parallel
Number of Beams:
6
Series:
FCR
Bore Type:
Round
Bore Diameter 1:
1/2 in
Coupling Material:
Stainless Steel
Shaft Locking Type:
Clamp On
Coupling Outside Diameter:
1 1/2 in
Package Quantity:
1
