Contactor Auxiliary Contact Block Iec - LADN223

Contactor Auxiliary Contact Block Iec - LADN223

Schneider Electric
SKU:
LADN223
|
UPC:
785901221111
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Contactor Auxiliary Contact Block Iec
Additional Information
Country of Origin:
France
Item:
Contactor Auxiliary Contact Block Iec
[Ui] Rated Insulation Voltage:
690 V IEC 60947-5-1 || 600 V UL || 600 V CSA
Mechanical Durability:
30 Mcycles
[Ith] Conventional Free Air Thermal Current:
10 A 60°C
Non-Overlap Time:
1.5 ms on de-energisation no overlap between NC and NO contact || 1.5 ms on energisation no overlap between NC and NO contact
Mounting Location:
front
Ambient Air Temperature For Storage:
-60-80°C
Ambient Air Temperature For Operation:
-5-60°C
Height:
48 mm
Device Short Name:
LADN
Insulation Resistance:
> 10 MOhm
Irms Rated Making Capacity:
140 A AC IEC 60947-5-1 || 250 A DC IEC 60947-5-1
Protection Type:
gG fuse 10 A
Environmental Characteristic:
normal environment
Range:
TeSys || TeSys Deca
Pole Contact Composition:
2 NO + 2 NC
Ip Degree Of Protection:
IP20 conforming to IEC 60529
Minimum Switching Current:
5 mA
[Ue] Rated Operational Voltage:
690 V AC 25...400 Hz
Operating Altitude:
9842.52 ft (3000 m)
Color:
dark grey
Depth:
42 mm
Width:
44 mm
[Ie] Rated Operational Current:
6 A120 V AC-15 || 1.04 A690 V AC-15 || 0.55 A125 V DC-13 || 0.1 A600 V DC-13
Protective Treatment:
TH IEC 60068
Product Certifications:
CB || UL || CSA || CCC || EAC || UKCA
Product Name:
TeSys Deca
Auxiliary Contacts Operation:
instantaneous
Product Or Component Type:
auxiliary contact block
Permissible Short-Time Rating:
100 A 60°C 1 s || 120 A 60°C 500 ms || 140 A 60°C 100 ms
Range Compatibility:
TeSys D CAD || TeSys D LC1D || TeSys Deca CAD || TeSys Deca LC1D
Standards:
EN/IEC 60947-5-1 || UL 60947-5-1 || CSA C22.2 No 60947-5-1 || GB/T 14048.5
Connections - Terminals:
spring terminals 2 2.5-2.5 mm²flexible without cable end || spring terminals 2 2.5-2.5 mm²rigid
Minimum Switching Voltage:
17 V
Rated Operational Voltage:
690 V AC 25 to 400 Hz
Rated Operational Current:
6 A at 120 V AC-15; 1.04 A at 690 V AC-15; 0.55 A at 125 V DC-13; 0.1 A at 600 V DC-13
Rated Insulation Voltage:
690 V IEC 60947-5-1; 600 V UL; 600 V CSA
Conventional Free Air Thermal Current:
10 A (at 140°F (60°C))
Package Quantity:
1
