Contact Block, 1NC/1NO, 30mm - 9001KA41

Contact Block, 1NC/1NO, 30mm - 9001KA41

Schneider Electric
SKU:
9001KA41
|
UPC:
785901498544
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Contact Block, Contact Form SPDT, Contact Rating 0.5A @ 120V AC, For Use With Schneider 9001K Series 30mm Operators, Action Momentary, 30 mm, Application Low Energy Circuits, NEMA Contact Rating Designation A600/Q600, Color Black, Terminal Connection Screw/Clamp, Standards CSA C22.2 No.14, IEC 60947-1, IEC 60947-5-1, IEC 60947-5-4, JIS C4520, JIS C852, UL 508, UL 60947-5-1, Safety Rating Class II Conforming to IEC 61140
Additional Information
Country of Origin:
United States
Item:
Contact Block
Contact Rating:
0.5A @ 120V AC
Size:
30 mm
Action:
Momentary
Application:
Automotive Chassis, Heavy Industrial Applications Where The Ptfe Additive Acts As An Additional Lubrication Barrier Against Metal-to-Metal Contact, Industrial - Machinery Tools, Overhead Garage Door Channels, Fan Motors, Slides, Gearsmarine - Cables,
Contact Form:
SPDT
Color:
Black
For Use With:
Schneider 9001K Series 30mm Operators
NEMA Contact Rating Designation:
A600/Q600
Safety Rating:
Class II Conforming to IEC 61140
Standards:
CSA C22.2 No.14, IEC 60947-1, IEC 60947-5-1, IEC 60947-5-4, JIS C4520, JIS C852, UL 508, UL 60947-5-1
Terminal Connection:
Screw/Clamp
Voltage:
600 VAC
[Ie] Rated Operational Current:
3 A 240 V, AC-15, A600-Q600 NEMA || 0.55 A 125 V, DC-13, A600-Q600 NEMA
Shock Resistance:
50 gn IEC 60068-2-27
Positive Opening:
without
Shape Of Screw Head:
cross slotted
Product Certifications:
UL 508 || NEMA
Ambient Air Temperature For Operation:
-25-70°C
[Ui] Rated Insulation Voltage:
250 V 3)IEC 60947-1
Ambient Air Temperature For Storage:
-40-70°C
Contact Operation:
logic reed || hermetically sealed
Device Short Name:
9001K
Electrical Shock Protection Class:
class II IEC 61140
Tightening Torque:
0.8-0.8 N.m IEC 60947-1
Ip Degree Of Protection:
IP20 IEC 60529
Vibration Resistance:
7 gn 2-500 Hz)IEC 60068-2-6
Short-Circuit Protection:
10 A cartridge fuse IEC 60947-5-1
[Us] Rated Supply Voltage:
120 V
[Icm] Rated Short-Circuit Making Capacity:
12 kA 600 V AC-15, 7200 VA || 15 kA 480 V AC-15, 7200 VA || 30 kA 240 V AC-15, 7200 VA || 60 kA 120 V AC-15, 7200 VA || 0.55 kA 125 V DC-13 || 0.1 kA 600 V DC-13 || 0.27 kA 250 V DC-13
Rated Breaking Capacity:
3 kA 240 V AC-15, 720 VA || 6 kA 120 V AC-15, 720 VA || 1.2 kA 600 V AC-15, 720 VA || 1.5 kA 480 V AC-15, 720 VA || 0.1 kA 600 V DC-13 || 0.27 kA 250 V DC-13 || 0.55 kA 125 V DC-13
Connections - Terminals:
screw-clamp terminals, screw clamp terminals, 1 x 0.22 to 2 x 2.5 mm² IEC 60947-1
[Uimp] Rated Impulse Withstand Voltage:
2.5 kV IEC 60947-1
Contacts Usage:
hermetically sealed contacts
[Ith] Conventional Free Air Thermal Current:
10 A
Product Or Component Type:
contact block
Contacts Type And Composition:
1 C/O
Protective Treatment:
TC
Rated Short Circuit Making Capacity:
12 kA 600 V AC-15, 7200 VA; 15 kA 480 V AC-15, 7200 VA; 30 kA 240 V AC-15, 7200 VA; 60 kA 120 V AC-15, 7200 VA; 0.55 kA 125 V DC-13; 0.1 kA 600 V DC-13; 0.27 kA 250 V DC-13
Rated Operational Current:
3 A 240 V, AC-15, A600-Q600 NEMA; 0.55 A 125 V, DC-13, A600-Q600 NEMA
Conventional Free Air Thermal Current:
10 A
Includes Mounting Block:
Not Applicable
Manufacturer Warranty Length:
18 mo
DC Contact Rating:
0.1 A @ 30 V
Connection Size:
30 mm
Switch Action:
Momentary/Logic Reed
Compatible with Series:
9001K, 9001SK
Compatible Operator:
Push Button
Terminal Connection Type:
Screw Clamp Terminals
AC Contact Rating:
0.1 A @ 32 V
Package Quantity:
1
