Connector, 30A, 4P, 3W, Coppr-Free Alum, 600V - ARC3034BC

Connector, 30A, 4P, 3W, Coppr-Free Alum, 600V - ARC3034BC

Appleton Electric
SKU:
ARC3034BC
|
UPC:
78138144057
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Connector, Current Rating 30 A, Grounding Style Style 2, Horsepower Rating 20 hp, Housing Color Gray, IP Rating Not Applicable, Number of Poles 4, Number of Wires 3, Phase Three, Resistance Properties Weather Resistant, Switch Rated No, Voltage Rating 250V DC, 600V AC, Cap Type No Cap or Cover, Connection Orientation Straight, Face Diameter 2.88 in, For Maximum Cable Diameter 1.25 in, For Minimum Cable Diameter 0.5 in, Grounding Grounded, Housing Material Aluminum, Market Industrial
Additional Information
Country of Origin:
Mexico
Number of Poles:
4
Number of Wires:
3
Switch Rated:
No
Grounding Style:
Style 2
Item:
Connector
NEMA Rating:
3, 3R, 4, 4X
HP:
20 hp
Voltage:
600V AC
Standards:
CSA Certified 065179, CSA Certified C22.2 No. 182.1, UL 1682, UL 1686, UL 50E, UL E145916, UL E145917
Material:
Copperfree Aluminum
Amps:
30 A
Phase:
Three
Overall Length:
6.4 in
Grounding:
Grounded
Housing Material Finish:
Epoxy Powder Coated
Wire Connection Type:
Screw Terminals
Reverse Service:
Yes
Connection Orientation:
Straight
NEMA Enclosure Rating:
3, 3R, 4, 4X
Polarized:
Yes
Insulation Material:
Glass-Filled Polyester
Shrouded:
Yes
Resistance Properties:
Weather Resistant
Voltage Rating:
250V DC, 600V AC
Cap Type:
No Cap or Cover
For Maximum Cable Diameter:
1.25 in
Housing Material:
Aluminum
Market:
Industrial
Power Indicating Light:
No
Minimum Wire Size:
10 AWG
For Minimum Cable Diameter:
0.5 in
Housing Color:
Gray
Maximum Operating Temperature:
107 Degrees C
Face Diameter:
2.88 in
For Environment:
Hazardous Location
Minimum Operating Temperature:
-40 Degrees C
Compatible with Series:
Powertite
Current Rating:
30 A
IP Rating:
Not Applicable
UL 94 Flammability Rating:
Not Rated
Horsepower Rating:
20 hp
Maximum Wire Size:
6 AWG
Package Quantity:
1
