Conduit Outlet Body, Aluminum, T - MOT-4
Conduit Outlet Body, Overall Width 3 in, Overall Height 4 in, Overall Length 13 in, Trade Size 1 1/4 in, Compatible Conduit Trade Size 1 1/4 in, Hub Size 1 1/4 in, Aluminum, Moguls, Compatible Conduit Type IMC, RMC, Back Type Flat, Body Capacity 104.9 cu in, Body Style T, Body Type Conduit Outlet Body, Color Gray, Connection Orientation Multi-Angle, Connection Type Threaded, Cover Included Yes, Finish Powder Coated, For Use With IMC, RMC, Gasket Included Yes, Hazardous Location No
- Country of Origin:
- Mexico
- Conduit Outlet Body Type:
- Conduit Outlet Body
- Item:
- Conduit Outlet Body
- Hazardous Location:
- No
- Hub Size:
- 1-1/4
- Series:
- Moguls
- Conduit Outlet Body Material:
- Aluminum
- Conduit Outlet Body Style:
- T
- Material:
- Aluminum, Copper Free (less than 4/10 of 1%)
- Conduit Outlet Body Capacity:
- 104.9 cu in
- Conduit Outlet Body Hub Size:
- 1 1/4 in
- Conduit Outlet Body Hub Style:
- Threaded
- For Use With:
- IMC, RMC
- Special Features:
- A raised dome cover permits additional wiring room. Furnished with captive ss screws and gasket. Volume is 54 cu. in.
- Back Type:
- Flat
- Color:
- Gray
- Standards:
- UL
- Conduit Outlet Hub Size:
- 1-1/4";Form=Form 1"
- Height:
- 4 in
- Finish:
- Powder Epoxy Paint
- Length:
- 13 in
- Width:
- 3 in
- Body Style:
- T
- Compatible Conduit Trade Size:
- 1 1/4 in
- Shape:
- T
- Body Type:
- Conduit Outlet Body
- Connection Type:
- Threaded
- Hub Style:
- Threaded
- Thread Size:
- 1 1/4 in
- Connection Orientation:
- Multi-Angle
- Number of Hubs:
- 3
- Trade Size:
- 1 1/4 in
- Body Capacity:
- 104.9 cu in
- Overall Height:
- 4 in
- Overall Width:
- 3 in
- Gasket Included:
- Yes
- Compatible Conduit Type:
- IMC, RMC
- Thread Gender:
- Female
- Thread Type:
- NPT
- Overall Length:
- 13 in
- Cover Included:
- Yes
- UPC:
- 783937000000
- Hub Pattern:
- T
- Dimensions:
- 13 in x 3 in x 4 in
- Package Net Weight:
- 4
- Hazardous Location Rating:
- Suitable for use in hazardous location applications when installed according to NEC Articles 501.10(b) (Class I, Division 2) or 502.10, 503.10, and 505.15 (Class I Zone 2).
- Finish Type:
- Powder Epoxy Paint
- Hazardous Rating(s):
- Suitable for use in hazardous location applications when installed according to NEC Articles 501.10(b) (Class I, Division 2) or 502.10, 503.10, and 505.15 (Class I Zone 2).
- Application:
- Mogul fittings are for use with rigid and IMC raceways. Use where standard conduit bodies do not provide adequate access and wiring area for the pulling of large and heavy conductors. For right angle bends where splices, pulls, and taps are needed in
- Each - Width:
- 3.000 in
- Type:
- Mogul Conduit Body With Cover & Gasket
- Package Quantity:
- 1
