Compound Gauge, -30 to 0 to 15 in Hg/psi, 1/4 in MNPT, Stainless Steel, Silver - 351009SW02LV/15#

Compound Gauge, -30 to 0 to 15 in Hg/psi, 1/4 in MNPT, Stainless Steel, Silver - 351009SW02LV/15#

Ashcroft
SKU:
351009SW02LV/15#
|
UPC:
759426832206
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Industrial Compound Gauge, Nominal Dial Size 3 1/2 in, Accuracy +/-1.0 Percent, Gauge Case Material 304 Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Metallic, IP/NEMA Rating IP54 (Plug Vented), IP65 (Plug Closed), NEMA 4 (Plug Closed), Primary Pressure Range 30 to 0 to 15, Dry Dampening Feature None, Vibration Resistance None
Additional Information
Country of Origin:
United States
Connection Location:
Lower
Item:
Industrial Compound Gauge
Connection Size:
1/4 in NPT
Gauge Application:
Pumps and Compressors, Boilers, Equipment Skids, Specialized OEM Equipment, Hydraulics and pneumatics, Severe Ambient Conditions
Range:
30 in Hg Vac to 15 psi
Accuracy:
+/-1.0%
Material:
304 Stainless steel
Color:
Silver
Application:
Refrigeration, Autoclave, Boilers, Water Pressure Testing, Equipment Skids, Hydraulics, Pneumatics, Pumps, Severe Ambient Conditions, OEM Applications
Diameter:
3.89";Dial Size (In.)=3-1/2"
Gauge Primary Range Values:
-30 to 0 to 15
Gauge Primary Range Units:
in Hg/psi
Gauge Connection Type:
MNPT
Gauge Connection Size:
1/4 in
Basic Gauge Case Material:
Stainless Steel
Case Color:
Metallic
Gauge Lens Material:
Polycarbonate
Gauge Accuracy:
+/-1.00%
Basic Gauge Sensor Material:
Stainless Steel
Manufacturers Warranty Length:
5 yr
Pressure and Vacuum Gauge Type:
Compound Gauge
Graduations:
3 psi, 5 in Hg
Basic Gauge Wetted Parts:
Stainless Steel
Gauge Panel Mountable:
No
Basic Gauge Lens Material:
Plastic
Calibration Certificate Included:
No
Max. Pressure (PSI):
15
Gauge Socket Material:
316 Stainless Steel
Liquid Filled:
No
Series:
1009
Operating Temp. Range:
-40 Degrees to 200 Degrees F
Gauge Sensor Material:
316 Stainless Steel
Gauge Nominal Dial Size:
3 1/2 in
Smallest Graduation:
0.5 psi, 1 in Hg
Gauge Case Material:
304 Stainless Steel
Gauge Case Color:
Stainless Steel
Gauge Connection Location:
Bottom
Gauge Primary Range Smallest Graduation:
1/0.5
Basic Gauge Socket Material:
Stainless Steel
Gauge Special Options:
PowerFlex(TM) Movement
Socket Material:
316L Stainless Steel
Standards:
ASME, CRN, RoHS
Process Connection Type:
NPT
Process Connection Size:
1/4 in
Pointer Material:
Aluminum
Vibration Resistance:
None
Case Depth:
1.25 in
IP/NEMA Rating:
IP54 (Plug Vented), IP65 (Plug Closed), NEMA 4 (Plug Closed)
Case Construction:
Welded Joint
Gauge Case Liquid:
None
Case Diameter:
3.89 in
Includes Vent Plug:
Yes
Process Temperature Range:
-40 Degrees to 250 Degrees F
Accuracy Grade:
ASME B40.100 Grade 1A
Sensor Material:
316L Stainless Steel
Includes Calibration Certificate:
No
Nominal Dial Size:
3 1/2 in
Bezel Mounting Type:
Bayonet
Compatible Process Media:
Deionized Water
Scale Type:
Single
Removable Bezel:
Yes
Process Connection Location:
Bottom
Field Fillable:
No
Process Connection Gender:
Male
Movement Material:
304 Stainless Steel
Includes Mounting Hardware:
No
Pressure Range Type:
Compound
Primary Scale Units:
in Hg/psi
Sensor Type:
Bourdon Tube
Primary Pressure Scale Color:
Black
Pressure Gauge Type:
Industrial Pressure Gauge
Dry Dampening Feature:
None
Blowout Safety Back:
No
Freeze Resistant Movement:
No
Manufacturer Warranty Length:
5 yr
Primary Pressure Range:
30 to 0 to 15
Ambient Operating Temperature Range:
-40 Degrees to 200 Degrees F (-40 Degrees to 93 Degrees C)
Panel-Mountable:
No
Accuracy Scale:
Full Scale
Liquid-Filled Case:
No
Dial Color:
White
Cleaned for Oxygen Service:
No
Dial Face Material:
Aluminum
Bezel Material:
304 Stainless Steel
Pointer Color:
Black
Lens Material:
Polycarbonate
Hazardous Location Rating:
Not Rated
Non-Sparking:
No
Package Quantity:
1
