Carbon Steel Electrical Enclosures, 6 in H, 4 in D, 6 in W, NEMA 4, Screw On - WA060604GSC

Carbon Steel Electrical Enclosures, 6 in H, 4 in D, 6 in W, NEMA 4, Screw On - WA060604GSC

Wiegmann
SKU:
WA060604GSC
|
UPC:
786725310050
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Enclosure NEMA Rating 3, 4, Material of Enclosure Carbon Steel, 6 in, Screw On Enclosure Cover Type, Solid / Clear Cover Solid, Closure Method Screws, Finish ANSI 61 Powder Coated, Color Gray, Depth 4 in, Enclosure Cover Features Stainless Steel Cover Screws, Neoprene Gasket, Height 6 in, Includes Stainless Steel Cover Screws, Metal Gauge 14 ga, Wall Mounting, Series WA-GSC, Standards CSA Certified, cULus, UL Listed, Usable Opening Depth 5.88 in, Width 6 in
Additional Information
Country of Origin:
Mexico
CAD Available:
Yes
Item:
Electrical Enclosures
Nominal Width:
6 in
Nominal Height:
6 in
Nominal Depth:
4 in
Enclosure NEMA Rating:
NEMA 4
Material of Enclosure:
Carbon Steel
Closure Method:
Screws
Enclosure Cover Type:
Screw On
Knockouts:
No
Metallic / Non-Metallic:
Metallic
Color:
Gray
Finish:
Polyester Powder
Mounting:
Wall
Solid / Clear Cover:
Solid
Gasket:
Neoprene
Metal Gauge:
14 ga
Standards:
CSA Certified, cULus, UL Listed
Includes:
Stainless Steel Cover Screws
Usable Opening Depth:
5.88 in
Series:
WA-GSC
Features:
Bodies and covers fabricated from 14 gauge carbon steel; Seams are continuously welded and ground smooth; Cover contains closed cell oil resistant neoprene gasket; Enclosure comes with stainless steel cover screws which thread into sealed wells to pr
Cover Type:
Screw Cover
Enclosure Material:
Steel
Weight:
4 lb.
Capacity:
128 cu.in
Application:
Designed for use as wiring box, junction box, pull box, and terminal box in many indoor or outdoor applications where dust or moisture is a problem.
NEMA Enclosure Rating:
4
Includes Knockouts:
Knockouts Not Included
Gasket Material:
Neoprene
Body Material Thickness:
14 ga
Cover Closure Type:
Screw On
Cover Material Thickness:
14 ga
Environment - MERCH:
Washdown
Cover Style:
Solid
Package Quantity:
1
