Carbon Steel Electrical Enclosures, 12 in H, 9 in D, 16 in W, NEMA 12, Screw On - WC12C16

Carbon Steel Electrical Enclosures, 12 in H, 9 in D, 16 in W, NEMA 12, Screw On - WC12C16

Wiegmann
SKU:
WC12C16
|
UPC:
786725441259
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Sloped Top Enclosure, Metallic, No Knockouts, NEMA Rating 12, 13, Hinged Enclosure Cover Type, Height 12 In., Width 16 In., Depth 9 In., Material Carbon Steel, Enclosure Cover Features Captivated Cover Screws, Metal Gauge 14, Color Gray, Finish ANSI 61 Gray Polyester Powder, Neoprene Gasket, Series Consolets, Pedestal Mounting, Usable Opening Depth 3.5 In., Standards UL, CSA, NEMA, Includes Captivated Cover Screws
Additional Information
Country of Origin:
United States
Item:
Electrical Enclosures
Nominal Width:
16 in
Nominal Height:
12 in
Nominal Depth:
9 in
Enclosure NEMA Rating:
NEMA 12
Material of Enclosure:
Carbon Steel
Closure Method:
Captive Screws
Enclosure Cover Type:
Screw On
Knockouts:
No
Metallic / Non-Metallic:
Metallic
Color:
Gray
Finish:
Polyester Powder
Mounting:
Pedestal
Solid / Clear Cover:
Solid
Metal Gauge:
14 ga
Gasket:
Neoprene
Standards:
CSA Certified, cULus, EU RoHS Compliant, UL Listed
Enclosure Cover Features:
Captivated Cover Screws
Series:
WC-C
Usable Opening Depth:
8.88 in
Material:
Carbon Steel
Includes:
Captive Cover Screws
Cover Type:
Screw On
Enclosure Material:
Steel
Features:
Fabricated from carbon steel; Seams are continuously welded and ground smooth; Grounding provisions
Weight:
20 lb.
Capacity:
1728 cu.in
Application:
Designed to house a variety of electronic control or instrumentation devices. Consolets provide protection from dust, dirt, oil, and water. Flexible design allows for mounting on either of two sides, creating control surfaces of 30 degrees or 60 degr
Gasket Material:
Oil Resistant Neoprene
Includes Knockouts:
Knockouts Not Included
NEMA Enclosure Rating:
12, 13
Package Quantity:
1
