Capacitor-Start/Run General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame - 31TT03

Capacitor-Start/Run General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame - 31TT03

Dayton
SKU:
31TT03
|
UPC:
190735256084
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 hp HP, Nameplate RPM 3,450, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 8.8/4.9-4.4 A, 56 Frame, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base, Motor Mounting Position Horizontal, Inverter Rated Not Inverter Rated
Additional Information
Country of Origin:
Mexico
Item:
General Purpose Motor
Motor Enclosure Design:
Open Drip Proof
Motor Mounting Type:
Rigid Base
HP:
1 hp
RPM Range:
3,001-3,600
Voltage:
115/208-230V AC
Frame:
56
Motor Thermal Protection:
None
Motor Service Factor:
1.25
No. of Speeds:
1
Voltage Compatibility:
115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC
Motor Application:
General Purpose
Nameplate RPM:
3,450
Motor Frame Material:
Steel
Motor Mounting Position:
Horizontal
Motor Shaft Design:
Keyed
Motor Shaft Rotation:
CW/CCW
Motor Design:
Capacitor-Start/Run
Standards:
UL (E47479)
RPM Group:
3001-3600
Inverter Rated:
Not Inverter Rated
Green Environmental Attribute:
Product Contributes To Reducing Energy Consumption
Ins. Class:
B
Manufacturers Warranty Length:
1 yr
Frame Material:
Rolled steel
Motor Efficiency Group:
Premium Efficient
Full Load Amps:
8.8/4.9-4.4 A
Nominal Efficiency:
80.4 %
Hz:
60 Hz
Duty:
Continuous
Length Less Shaft:
10 7/16 in
Shaft Length:
1 7/8 in
Max. Ambient Temp.:
40 Degrees C
Motor Bearings:
Ball
Green Certification or Other Recognition:
Energy Aware
Phase:
Single
Overall Length:
12 3/8 in
Shaft Dia.:
5/8 in
Includes:
Start/Run Capacitors
Duty Cycle:
Continuous
Capacitor Required:
Yes
RPM @ 50Hz:
Not Applicable
Full Load Amps @ 50Hz:
Not Applicable
Voltage @ 50Hz:
Not Applicable
HP @ 50Hz:
Not Applicable
Service Factor @ 50Hz:
Not Applicable
Package Quantity:
1
