Capacitor-Start Belt Drive Motor, 1/2 HP, 56 Frame, 115/208-230V AC Voltage, 1,725 Nameplate RPM - 1AGG3

Capacitor-Start Belt Drive Motor, 1/2 HP, 56 Frame, 115/208-230V AC Voltage, 1,725 Nameplate RPM - 1AGG3

SKU:
1AGG3
|
UPC:
190735131237
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Belt Drive Motor, Single Phase, Motor Design Capacitor-Start, 1/2 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115/208-230V AC, 7.2/3.6-3.6 A Full Load Amps, 56 Frame, Usable @ 208V Yes, Usable @ 200V No, 60 Hz Hz, Motor Service Factor 1.25, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Dripproof, Motor Mounting Type Cradle Base, Motor Mounting Position All Angle
Additional Information
Country of Origin:
United States
Item:
Belt Drive Motor
Motor Design:
Capacitor-Start
Motor Enclosure Design:
Open Dripproof
HP:
1/2
No. of Speeds:
1
RPM Range:
1,701-1,800
Nameplate RPM:
1,725
Voltage:
115/208-230V AC
Frame:
56
Motor Mounting Type:
Cradle Base
Shaft Dia.:
5/8 in
Motor Thermal Protection:
Auto
Motor Service Factor:
1.25
Voltage Compatibility:
115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC
Phase:
Single
Motor Application:
HVAC/R
Motor Sub Application:
Belt Drive Fan/Blower
Length Less Shaft:
8 13/16 in
Motor Bearings:
Ball
Motor Frame Material:
Steel
Motor Mounting Position:
All Angle
Includes:
Capacitor
Standards:
CSA Certified, UL Recognized
Frame Material:
Rolled steel
Motor Shaft Rotation:
CW/CCW
Ins. Class:
B
Ring to Ring Center:
8 1/8 in
Overall Length:
10 1/2 in
Hz:
60 Hz
Shaft Length:
1 7/8 in
Duty:
Continuous
Max. Ambient Temp.:
104 Degrees F
Resilient Ring Dia.:
2 1/4 in
Body Dia.:
5 5/8 in
Mounting Stud Pattern:
3-5/8 in x 3-5/8 in
Full Load Amps:
7.2/3.6-3.6 A
Motor Shaft Design:
Keyed
Usable @ 200V:
No
Usable @ 208V:
Yes
Duty Cycle:
Continuous
Package Quantity:
1
