Brake, Magnetic, Watertight, Torque 3 Ft-Lb - 2LYU1

Brake, Magnetic, Watertight, Torque 3 Ft-Lb - 2LYU1

Dayton
SKU:
2LYU1
|
UPC:
190735222805
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Brake, Clutch/Brake Type Double C-Face Magnetic Disc Brake, Coil Voltage 110/208-220V AC @ 50 Hz, 115/208-230V AC @ 60 Hz, Operating Voltage 110/208-220V AC @ 50 Hz, 115/208-230V AC @ 60 Hz, Enclosure Type Totally Enclosed, Static Torque 3 ft-lb, Horsepower @ RPM 1 hp @ 1725 RPM, 2 hp @ 3450 RPM, Shaft Diameter 5/8 in, Maximum Speed 3,450 RPM, Mounting Location NEMA C-Face Flanges on Motors and Gear Reducers
Additional Information
Country of Origin:
United States
Item:
Brake
For Use With:
Single and Three Phase General Purpose C-Face Motors for Indoor/Outdoor Applications
Type:
Double C-Face Magnetic Disc
Shaft Dia. (In.):
5/8 in
Length (In.):
4.875 in
Coil Volts:
115/208-230V AC Or 110/208-220V AC
Static Torque (Ft.-Lb.):
3
NEMA/IEC Frame:
56C
Enclosure:
Waterproof/Dust-Tight
Max. RPM:
3,450 RPM
Max. HP @ 1725 RPM:
1 hp
Features:
Easily Installed
Includes:
Hardware
Phase:
Single
Brake Mouting Position:
Horizontal
Ambient (C):
40 Degrees C
Function:
Spring Set Brake With Automatic Reset Release
Lever Type:
Manual Release
Converts:
Converts NEMA C-Face Motors and Gear Reducers to a Geared Brake Motor
Series:
60 Series
Power Lead Length (In.):
15
Amps Holding:
0.22/0.11
Duty:
Continuous
Application:
Crane Trolleys and High Speed Doors, Stops and Holds Rotating Loads on Conveyors
Service Factor:
1
Max. HP @ 3450 RPM:
2 hp
Dia. (In.):
6 7/8 in
Voltage @ 50 Hz:
110/208 a 220
Hz:
60/50
Inrush Amps:
1.74/0.87
Voltage @ 60 Hz:
115/208 a 230
Mounts On:
NEMA C-Face Flanges On Motors And Gear Reducers
Agency Compliance:
CSA
Finish:
Gray Enamel Paint
Standards:
CSA Certified
Overall Length:
4.88 in
Outside Diameter:
6.88 in
Horsepower @ RPM:
1 hp @ 1725 RPM, 2 hp @ 3450 RPM
Clutch/Brake Type:
Double C-Face Magnetic Disc Brake
Shaft Diameter:
5/8 in
Lever Release:
Manual
Inrush Current:
1.74/0.87 A
Housing Material Finish:
Gray Enamel Paint
Operating Voltage:
110/208-220V AC @ 50 Hz, 115/208-230V AC @ 60 Hz
Maximum Ambient Temperature:
40 Degrees C
Enclosure Type:
Totally Enclosed
Static Torque:
3 ft-lb
Continuous Duty:
Yes
Holding Current:
0.22/0.11 A
Coil Voltage:
110/208-220V AC @ 50 Hz, 115/208-230V AC @ 60 Hz
Maximum Speed:
3,450 RPM
Mounting Orientation:
Horizontal
Frequency:
50 Hz, 60 Hz
Package Quantity:
1
