Blower, 13-1/2 in. Wheel Dia., 32-3/8in. D - 48LW23

Blower, 13-1/2 in. Wheel Dia., 32-3/8in. D - 48LW23

Dayton
SKU:
48LW23
|
UPC:
190735891285
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Blower, Wheel Type Backward-Inclined, Drive Type Belt Drive, Includes Drive Package No, Assembly Unassembled, Wheel Diameter 13 1/2 in, Maximum Inlet Air Temperature 250 Degrees F, Shaft Diameter 1 in, Bearing Type Ball, Wheel Material Steel, Housing Material Steel, Number of Inlets 1, Inlet Diameter 14 1/2 in, Outlet Shape Rectangular, Outlet Height 14 5/8 in, Outlet Width 10 3/4 in, Outlet Diameter Not Applicable, Minimum Motor Horsepower 1/4 hp, Maximum Motor Horsepower 5 hp
Additional Information
Country of Origin:
United States
Promotion Restriction:
Not eligible for promotion
Wheel Dia. (In.):
13 1/2 in
Dimension C (In.):
14 5/8 in
Assembled/Unassembled:
Assembled
Dimension B (In.):
13 1/2 in
Dimension A (In.):
17 5/8 in
Housing Material:
Steel
Dimension F (In.):
16 in
Type:
Backward Incline Belt Drive less Drive Package
Item:
Blower
Wheel Material:
Steel
Dimension K (In.):
12 5/8 in
Dimension N (In.):
7 in
Dimension P (In.):
14 1/2 in
Depth (In.):
32 3/8 in
Dimension X (In.):
17 in
Dimension T (In.):
20 in
Outlet Width (In.):
10 3/4 in
Dimension L (In.):
11 3/8 in
Dimension Q (In.):
12 3/8 in
Dimension S (In.):
25 7/8 in
Motor HP Range:
1/4 to 5
Dimension R (In.):
13 7/8 in
Rotation:
CW
Includes:
Epoxy Coated Steel Weather Proof Drive Cover
Width (In.):
24 in
Dimension M (In.):
24 3/8 in
Inlet Dia. (In.):
14 1/2 in
Dimension J (In.):
9 3/8 in
Dimension E (In.):
13 1/2 in
Dimension H (In.):
11 1/8 in
Bearing Type:
Ball
Height (In.):
28 1/8 in
Dimension Y (In.):
1/2 in
Shaft Dia. (In.):
1 in
Housing Finish:
Gray Baked Polyester Epoxy
Max. Inlet Temp. (Deg. F):
250 Degrees F
Outlet Height (In.):
14 5/8 in
Dimension D (In.):
10 3/4 in
Assembly:
Unassembled
Shaft Diameter:
1 in
Maximum Inlet Air Temperature:
250 Degrees F
Number of Inlets:
1
Outlet Height:
14 5/8 in
Outlet Width:
10 3/4 in
Manufacturer Warranty Length:
1 yr Limited
Wheel Diameter:
13 1/2 in
Overall Depth:
32 3/8 in
Wheel Type:
Backward-Inclined
Inlet Diameter:
14 1/2 in
Overall Width:
24 in
Outlet Diameter:
Not Applicable
Maximum Motor Horsepower:
5 hp
Drive Type:
Belt Drive
Includes Drive Package:
No
Housing Color:
Gray
Housing Material Finish:
Gray Baked Polyester Epoxy
Overall Height:
28 1/8 in
Outlet Shape:
Rectangular
Minimum Motor Horsepower:
1/4 hp
Includes Motor:
No
Standards:
AMCA Air Performance Certified
Package Quantity:
1
