Bench Grinder, 10 in Max. Wheel Dia, 1 in Max. Wheel Thickness, 36/60 Grinding Wheel Grit - 2LKT3

Bench Grinder, 10 in Max. Wheel Dia, 1 in Max. Wheel Thickness, 36/60 Grinding Wheel Grit - 2LKT3

Dayton
SKU:
2LKT3
|
UPC:
190735222461
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Bench Grinder, For Max. Wheel Dia. 10 in, For Max. Wheel Thickness 1 in, Grinding Wheel Grit 36/60, Speed Setting Single Speed, Arbor Size 1 in, Dust Management Dust Management Included, Lights Included No, Application Deburring, Grinding, Sharpening, Bearing Type Ball Bearing
Additional Information
Country of Origin:
Multiple
Item:
Bench Grinder
For Max. Wheel Dia.:
10 in
Finishing Wheel Width:
1";Finishing Function=Grinding"
Max. RPM:
1725
Phase:
Three
Arbor Hole Size:
1";Amps=3.3/1.65"
Standards:
CSA Certified
For Max. Wheel Thickness:
1 in
Grinding Wheel Grit:
36/60
Voltage:
220/440V AC
HP:
1
Arbor Size:
1 in
Finishing Wheel Diameter:
10";Wheels Center-Center=20""
Includes:
(2) Adjustable Eye Shields with Hurricane Bolts, (2) Grinding Wheels, (2) Ratcheting Tool Rests, (2) Spark Arrestors, 6 ft Cord, Dust Collection Hose Assembly, Toggle Switch
Light:
No
Grit:
36 and 60
Hz:
60
No Load RPM:
1725
Wheel Width:
1";Exhaust Port Size=2-1/2""
Wheel Material:
Aluminum Oxide
Overall Length:
15 in
Dust Collection:
Yes
Wheel Dia.:
10";Overall Height=17 1/2 in"
Features:
Adjustable Eyeshields, Adjustable Spark Arrestors, Adjustable Tool Rests, Dust Collection Hose Assembly, Includes Locking Toggle Switch
Overall Width:
24 in
Application:
Deburring, Grinding, Sharpening
Current:
1.65 A, 3.3 A
Wheel Distance:
19 1/2 in
Max. Wheel Speed:
1,725 RPM
Switch Type:
Toggle
Dust Collection Port Size:
2 1/2 in
Spindle Thread Size:
M24x2
Number of Speed Settings:
1
Lights Included:
No
Min. Wheel Speed:
1,725 RPM
Dust Management:
Dust Management Included
Horsepower:
1 hp
Dust Sealed Switch:
No
Max. Disc Speed:
1,725 RPM
Tool Weight:
110.5 lb
Plug Type:
Wire Leads
Housing Material:
Aluminum, Steel
Cord Length:
6 ft
Speed Setting:
Single Speed
Electrical Connection:
Wire Lead
Bearing Type:
Ball Bearing
Electrical Protection:
Grounded
Frequency:
60 Hz
Duty:
Heavy Duty
For Use On:
Alloy and Carbon Metals
Number of Pieces:
1
Arbor Diameter:
1 in
Base Footprint -Depth:
10 1/8 in
Power Cord Length:
6 ft
Tool Rest Material:
Aluminum
Base Footprint -Width:
10 15/16 in
Power Cord - NEMA Plug Configuration:
No Plug
Eye Shield Material:
Polycarbonate
Motor Speed - Minimum:
Not Applicable
Base Material:
Cast Iron
Includes Dust Management:
Dust Management Included
Wattage:
735 W
Includes Lights:
Light Not Included
Power Cord - Number of Wires:
3
Power Cord - Wire Size:
16 AWG
Motor Type:
Totally Enclosed Air-Over
Wheel Flange Diameter:
3 5/16 in
Material Compatibility:
Alloys, Carbon Metals
Manufacturer Warranty:
1 Yr
Power Cord Designation:
SJT
For Wheel Thickness - Maximum:
1 in
Arbor Thread:
M24x2
Arbor Material:
Steel
For Wheel Diameter - Maximum:
10 in
Sealed Switch:
No Dust Protection
End Shield Material:
Cast Iron
Sound Level:
75 dB
Minimum Extraction Volume:
400 cfm
Includes Ground:
Grounded
Mounting Holes - Diameter:
7/16 in
Wheel Diameter:
10 in
Motor Speed - Maximum:
1,725 RPM
Motor Housing Material:
Aluminum; Steel
For Wheel Diameter - Minimum:
Not Applicable
Package Quantity:
1
