Air Impact Wrench, 1" Square Drive, Pistol - CP7779

Air Impact Wrench, 1" Square Drive, Pistol - CP7779

Chicago Pneumatic
SKU:
CP7779
|
UPC:
15451779634
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Impact Wrench, Power Source Air Powered, Air Consumption 40 cfm, Air Inlet 3/8 in NPT, Air Pressure 90 psi, Max. Air Pressure 90 psi, Min. Air Pressure 90 psi, Min. Hose Size 1/2 in, Exhaust Location Bottom, Duty Rating General Duty, Breakaway Torque 1,440 ft-lb, Fastening Torque 1,080 ft-lb, Free Speed 6,500 RPM, Impact Rated Yes, Impact Sound Level 108 dB, Impacts per Minute 1,200, Number of Speed Settings 3, Power to Weight Ratio 200 ft-lb/lb, Max. Bolt Capacity 1/2 in, Drive Size 1 in Square
Additional Information
Country of Origin:
Taiwan, Province of China
Item:
Impact Wrench
Free Speed:
6,500 RPM
Air Inlet:
3/8 in NPT
Handle Type:
Pistol Grip
Torque Range:
300 to 1440 ft.-lb.
Body Style - Air Tools:
Pistol
Handle Material:
Composite
Blows per Minute - Air Tools:
1200
Max. Torque:
1440 ft.-lb.
Average CFM @ 15 Second Run Time:
10.00
Anvil Length - Air Impacts:
1.000";Item - Air Impact Wrenches=Air Impact Wrench"
Required Pressure:
90 psi
Overall Length:
8 1/8 in
Duty Cycle - Air Tools:
General Duty
Min. Hose Size:
1/2 in
Retainer Type - Air Impacts:
Ring / Thru Hole
Housing Material:
Composite
Air Inlet Size - Air Tools:
3/8 NPT"
Drive Size - Air Tools:
1 Square"
Features:
360 Degrees Swivel Air Inlet, One-Hand Power Adjustment, One-Hand Reverse System, Variable Speed Trigger
Max. Bolt Capacity:
1/2 in
Anvil Type - Air Impacts:
Standard
Tool Weight:
7.2 lb
CFM @ Full Load:
40.2
Retainer Type:
Friction Ring, Through Hole
Impacts per Minute:
1,200
Drive Size:
1 in Square
Impact Rated:
Yes
Breakaway Torque:
1,440 ft-lb
Air Pressure:
90 psi
Tool Style:
Compact
Drive Type:
Standard
Exhaust Location:
Bottom
Min. Air Pressure:
90 psi
Fastening Torque:
1,080 ft-lb
Power Source:
Air Powered
Max. Air Pressure:
90 psi
Vibration Level:
13.0 m/sq sec
Impact Sound Level:
108 dB
Standards:
EN ISO 11148-6
Duty Rating:
General Duty
Clutch Style:
Twin Hammer
Number of Speed Settings:
3
Built-In Light:
No
Power to Weight Ratio:
200 ft-lb/lb
Air Consumption:
40 cfm
Package Quantity:
1
