Agricultural Fan Motor, Permanent Split Capacitor, 1/3 HP, 115/230V AC, 1,700 Nameplate RPM - 1YAZ5

Agricultural Fan Motor, Permanent Split Capacitor, 1/3 HP, 115/230V AC, 1,700 Nameplate RPM - 1YAZ5

Dayton
SKU:
1YAZ5
|
UPC:
190735150177
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Agricultural Fan Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/3 HP, Nameplate RPM 1,700, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 3.8/1.9 A, 48YZ Frame, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Cradle Base, Motor Mounting Position Horizontal, Motor Frame Material Rolled Steel
Additional Information
Country of Origin:
Mexico
Item:
Agricultural Fan Motor
Motor Design:
Permanent Split Capacitor
Phase:
Single
HP:
1/3
RPM Range:
1,601-1,700
Voltage:
115/230V AC
Frame:
48YZ
Motor Service Factor:
1
Motor Thermal Protection:
Auto
Motor Enclosure Design:
Totally Enclosed Air-Over
Nameplate RPM:
1,700
Motor Application:
Farm Duty
Motor Frame Material:
Rolled Steel
Motor Mounting Position:
Horizontal
Motor Mounting Type:
Cradle Base
Motor Sub Application:
Agricultural Fan
Motor Shaft Design:
Double-Flat
Motor Shaft Rotation:
CW/CCW
Standards:
CSA Certified (258501), UL Recognized (E37403)
Shaft Length:
2 1/2 in
Includes:
5/8 in Shaft Adapter, Extended Thru Bolts, Gasketed Capacitor Cover, Shaft Key, Shaft Slinger
Shaft Dia.:
1/2 in
Full Load Amps:
3.8/1.9 A
Ins. Class:
B
Voltage Compatibility:
115/200-230V AC, 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 230V AC, 240V AC
Max. Ambient Temperature:
40 Degrees C
Motor Bearings:
Ball
Nominal Efficiency:
61 %
Frame Material:
Rolled steel
Overall Length:
10 7/16 in
Duty:
Continuous Air Over
Hz:
60 Hz
Finish:
Gray
Capacitor Required:
Included
Item - Farm Duty Motors:
Agricultural Fan Motor
Length Less Shaft:
7 15/16 in
Duty Cycle:
Continuous
No. of Speeds:
1
Max. Ambient Temp.:
40 Degrees C
Application:
Farm Duty
Replacement For:
4M252
Package Quantity:
1
