50A Twist-Lock Connector 2P 3W 250VAC BK/WT - CS8264C

50A Twist-Lock Connector 2P 3W 250VAC BK/WT - CS8264C

Hubbell
SKU:
CS8264C
|
UPC:
783585828466
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Locking Connector, Connection Orientation Straight, Current Rating 50 A, Housing Color Black, White, Housing Material Nylon, IP Rating IP20, NEMA Receptacle Configuration Non-NEMA, Number of Poles 2, Number of Wires 3, Phase Single, Resistance Properties Heat Resistant, Shrouded No, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, Cap Type No Cap or Cover, Contact Material Brass, For Maximum Cable Diameter 1.25 in, For Minimum Cable Diameter 0.83 in
Additional Information
Country of Origin:
United States
Item:
Locking Connector
Amps - Plugs and Receptacles:
50
NEMA Plug Configuration - Plugs and Receptacles:
50A, Non-NEMA
Voltage:
250VAC
NEMA Configuration:
Non-NEMA
Number of Poles:
2
Number of Wires:
3
Wiring Style:
Standard
Color:
Black/White
Grade - Plugs and Receptacles:
Industrial
Shrouded / Non-Shrouded:
Non-Shrouded
Item - Plugs and Receptacles:
Locking Connector
Power Indicator:
No
Phase:
Single
Cord Size:
0.750 in to 1.125 in
Amps:
50
Material:
Super Tough Nylon
Standards:
CSA Certified C22.2 No. 42, UL 498
IP Rating:
IP20
Grade:
Industrial/Commercial
Corrosion Resistant:
No
Antimicrobial:
No
Color - Plugs and Receptacles:
Black/White
Voltage - Plugs and Receptacles:
250V AC
Body Material:
Black Nylon
Special Features:
Terminals identified in accordance with UL 498 (X, Y, Z, White, Green)
Power Indicating Light:
No
NEMA Receptacle Configuration:
Non-NEMA
Maximum Operating Temperature:
75 Degrees C
Wire Connection Type:
Screw Terminals
Overall Length:
6.5 in
Grounding:
Grounded
Housing Color:
Black, White
Connection Orientation:
Straight
UL 94 Flammability Rating:
HB
Outside Diameter:
2.563 in
Current Rating:
50 A
Minimum Wire Size:
10 AWG
Voltage Rating:
250V AC
For Maximum Cable Diameter:
1.25 in
Market:
Industrial
Minimum Operating Temperature:
-40 Degrees C
Cap Type:
No Cap or Cover
Maximum Wire Size:
6 AWG
For Minimum Cable Diameter:
0.83 in
Resistance Properties:
Heat Resistant
Contact Material:
Brass
For Location:
Indoor
Shrouded:
No
Midget Locking:
No
Housing Material:
Nylon
For Environment:
Dry
Temp. Rise:
Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75.
Dielectric Strength:
Withstands 2,000V minimum
Type:
Connector Body
Cord Dia. Range:
(21.08-31.75) .830-1.250""
Weight:
0.95
Flame Resistant:
HB or better
Wire Size:
#10 AWG to #6 AWG
Display Size:
Standard
Cable Range:
0.830 - 1.250 in
Height:
2.50 in
OEM Brand Name:
Hubbell Wiring Device-Kellems
Voltage Rating Description:
250 V
Length:
6.50 in
Operating Temperature:
Maximum continuous 75°C and minimum -40°C without Impact
Environmental Conditions:
Indoor Dry Unless Protected By Additional Means
Dimensions:
6.50 in x 2.56 in x 2.50 in
Item Type:
Insulgrip Connector
Width:
2.56 in
Current / Amperage Rating:
50 A
Cord Range:
.830-1.250"(21.08-31.75)"
Industry Standard(s):
Certified to CSA C22.2 No.42 Listed to UL 498
Amperage Rating:
50 A
Material - Mounting Hardware:
Cord Mounted
Connectivity:
Pressure Terminal Screws
Insulation:
Insulated Body
Performance:
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - HB or better Environmental - Operating Temperatures - Maximum cont
Application:
Heavy Duty Industrial
Package Quantity:
1
