50A Flanged Locking Inlet 2P 3W 250VAC Silver - CS8275

50A Flanged Locking Inlet 2P 3W 250VAC Silver - CS8275

Hubbell
SKU:
CS8275
|
UPC:
783585829005
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Flanged Locking Inlet, Current Rating 50 A, Flange Material Steel, Housing Color Silver, IP Rating IP20, Mount Type Flush, NEMA Enclosure Rating 1, NEMA Plug Configuration Non-NEMA, Number of Blades 3, Number of Poles 2, Phase Single, Resistance Properties Moisture Resistant, Heat Resistant, Voltage Rating 250V AC, Wiring Style Standard, Face Diameter 2.17 in, Flange Diameter 3.5 in, Flange Type Flanged, Grounding Grounded, Housing Material Steel, Maximum Wire Size 6 AWG
Additional Information
Country of Origin:
United States
Item:
Flanged Locking Inlet
NEMA Configuration:
Non-NEMA
Voltage:
250V AC
Amps:
50
Color:
Gray
Number of Poles:
2
Number of Wires:
3
Phase:
Single
Shrouded / Non-Shrouded:
Non-Shrouded
Wiring Style:
Standard
IP Rating:
IP20
Material:
Zinc-Plated Steel
Grade:
General Use
Mounting Type:
Flush Mount
Standards:
CSA C22.2 No. 42, UL 498
NEMA Rating:
1
Special Features:
Molded In or Stamped On
Resistance Properties:
Moisture Resistant, Heat Resistant
Insulation Material:
Phenolic
Market:
Industrial
Face Diameter:
2.17 in
Number of Blades:
3
Maximum Operating Temperature:
75 Degrees C
Overall Depth:
2.63 in
Maximum Wire Size:
6 AWG
NEMA Enclosure Rating:
1
Mount Type:
Flush
Housing Material:
Steel
NEMA Plug Configuration:
Non-NEMA
For Location:
Indoor
Grounding:
Grounded
Current Rating:
50 A
Wire Connection Type:
Screw Terminals
Voltage Rating:
250V AC
Flange Type:
Flanged
Minimum Wire Size:
10 AWG
UL 94 Flammability Rating:
V-0
Flange Material:
Steel
Flange Diameter:
3.5 in
For Environment:
Dry
Blade Material:
Brass
Housing Color:
Silver
Minimum Operating Temperature:
-40 Degrees C
Shrouded:
No
Housing Material Finish:
Zinc Plated
Terminal Designations:
Terminals identified in accordance with UL 498 (X, Y, Z, White, Green)
Weight (Lbs.):
0.85
Flammability:
UL 94 VO for Receptacles and Inlets. HB or better for Plugs and Connectors.
Lock Type:
Twist-lock
Temp. Rise:
Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75.
Wire Size:
#6AWG
Operating Temp.:
Maximum continuous 75A Deg C; minimum –40A Deg C (w/o impact)
Type:
Flanged Inlet
Width:
2.62 in
Item Type:
Standard Single
Material - Mounting Hardware:
Screw Mounting
Industry Standard(s):
Certified to CSA C22.2 No.42 Listed to UL 498
Dimensions:
3.50 in x 2.62 in x 2.17 in
Current / Amperage Rating:
50 A
OEM Brand Name:
Hubbell Wiring Device-Kellems
Operating Temperature:
Maximum continuous 75°C and minimum -40°C without Impact
Environmental Conditions:
Indoor Dry Unless Protected By Additional Means
Connectivity:
Pressure Terminal Screws
Performance:
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V0 Environmental - Operating Temperatures - Maximum continuo
Voltage Rating Description:
250 V
Height:
2.17 in
Amperage Rating:
50 A
Application:
Extra Heavy Duty Industrial
Display Size:
Standard Sized Product
Length:
3.50 in
Dielectric Strength:
Withstands 2,000V minimum
Package Quantity:
1
