30A Watertight Locking Connector 3P 4W 125/250VAC L14-30R - HBL29W74

30A Watertight Locking Connector 3P 4W 125/250VAC L14-30R - HBL29W74

Hubbell
SKU:
HBL29W74
|
UPC:
783585131870
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Watertight Locking Connector, Connection Orientation Straight, Current Rating 30 A, Housing Color Yellow, Housing Material Thermoplastic Elastomer, IP Rating IP69K, NEMA Receptacle Configuration L14-30R, Number of Poles 3, Number of Wires 4, Phase Single, Resistance Properties Corrosion Resistant, Moisture Resistant, UV/Sunlight Resistant, Shrouded Yes, Voltage Rating 125/250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, Cap Type Press-On Cap
Additional Information
Country of Origin:
United States
Item:
Watertight Locking Connector
Amps:
30
Voltage:
125/250VAC
NEMA Configuration:
L14-30
Number of Poles:
3
Number of Wires:
4
Color:
Yellow
Color - Plugs and Receptacles:
Yellow
Special Features:
Corrosion resistant
Antimicrobial:
No
HP:
2.0
Item - Plugs and Receptacles:
Watertight Locking Connector
NEMA Rating:
4, 4X, 6, 6P
Grade - Plugs and Receptacles:
Industrial
Power Indicator:
No
Voltage - Plugs and Receptacles:
125/250V AC
Material:
Thermoplastic Elastomer, Valox
IP Rating:
IP69K
Wiring Style:
Standard
Phase:
Single
Amps - Plugs and Receptacles:
30
Cord Size:
0.375 in to 1.125 in
Corrosion Resistant:
Yes
Grade:
Industrial/Commercial
Standards:
ANSI
Shrouded / Non-Shrouded:
Non-Shrouded
NEMA Plug Configuration - Plugs and Receptacles:
L14-30R
Body Material:
Thermoplastic Elastomer
Overall Length:
2.77 in
Outside Diameter:
2.77 in
NEMA Receptacle Configuration:
L14-30R
Shrouded:
Yes
Horsepower Rating:
2 hp
Maximum Operating Temperature:
60 Degrees C
NEMA Enclosure Rating:
12, 4, 4X, 6, 6P
For Minimum Cable Diameter:
0.375 in
Power Indicating Light:
No
Contact Material:
Nickel-Plated Brass
For Maximum Cable Diameter:
1 in
Housing Color:
Yellow
Midget Locking:
No
Current Rating:
30 A
Cap Type:
Press-On Cap
Wire Connection Type:
Screw Terminals
Housing Material:
Thermoplastic Elastomer
Resistance Properties:
Corrosion Resistant, Moisture Resistant, UV/Sunlight Resistant
Minimum Wire Size:
18 AWG
Market:
Industrial
Voltage Rating:
125/250V AC
Maximum Wire Size:
8 AWG
Minimum Operating Temperature:
-40 Degrees C
Connection Orientation:
Straight
UL 94 Flammability Rating:
HB
UV Resistance:
All Exposed Materials are UV Stabilized
Retainer Material:
Clear Polycarbonate
Temp. Rise:
30°C
Dielectric Strength:
2500V AC
Bushing Material:
Black Elastomer
Operating Temp.:
-40 to 60°C
Length:
2.77 in
Type:
Connector Body
Height:
5.67 in
Width:
2.77 in
Wire Size:
Min Cords
Amperage Rating:
30 A
Industry Standard(s):
Meets NEMA WD-1, WD-6 And ANSI Standards
Current / Amperage Rating:
30 A
Performance:
Electrical - Current Interrupting - Rated for current interruption per UL498 Electrical - Dielectric Voltage - 2500V AC Electrical - Max Working Voltage - As marked Electrical - Temperature Rise - 30°C max per UL498 at rated current Environmental -
Dimensions:
2.77 in x 2.77 in x 5.67 in
Item Type:
30A Watertight Twist-Lock® Connector
Voltage Rating Description:
125/250 VAC
Package Quantity:
1
