30A Twist-Lock Receptacle 3P 4W 250VAC BK - HBL3430G

30A Twist-Lock Receptacle 3P 4W 250VAC BK - HBL3430G

Hubbell
SKU:
HBL3430G
|
UPC:
783585333250
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Locking Receptacle, Connection Orientation Straight, Current Rating 30 A, Flange Type Non-Flanged, Housing Color Black, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating 1, NEMA Receptacle Configuration Non-NEMA, Number of Gangs 1, Number of Poles 3, Number of Wires 4, Phase Three, Polarized Yes, Shrouded No, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, AFCI No, Contact Material Brass, Cover Type No Cover, Flange Diameter Not Applicable
Additional Information
Country of Origin:
United States
Item:
Locking Receptacle
NEMA Configuration:
Non-NEMA
Voltage:
250V AC
Amps:
30
Color:
Black
Number of Poles:
3
Number of Wires:
4
Phase:
Three
Shrouded / Non-Shrouded:
Non-Shrouded
Wiring Style:
Standard
IP Rating:
IP20
Special Features:
Corrosion resistant
Material:
Impact Modified PBT
NEMA Rating:
12, 4X
Grade:
Industrial
Mounting Type:
Flush Mount
Standards:
CSA Certified C22.2 No. 42, Federal Specification W-C-596, UL 498
Flange Height:
Not Applicable
Flange Width:
Not Applicable
Flange Diameter:
Not Applicable
Current Rating:
30 A
For Location:
Indoor
Resistance Properties:
Impact Resistant
Connection Orientation:
Straight
Cover Type:
No Cover
Voltage Rating:
250V AC
Housing Material:
Nylon
Maximum Operating Temperature:
75 Degrees C
Contact Material:
Brass
Polarized:
Yes
Mount Type:
Flush
Maximum Wire Size:
8 AWG
Market:
Industrial
UL 94 Flammability Rating:
V-2
Includes:
Mounting Hardware
Housing Color:
Black
Minimum Wire Size:
16 AWG
NEMA Enclosure Rating:
1
For Environment:
Dry
Flange Type:
Non-Flanged
Number of Gangs:
1
Minimum Operating Temperature:
-40 Degrees C
Grounding:
Grounded
Includes Mounting Hardware:
Yes
AFCI:
No
NEMA Receptacle Configuration:
Non-NEMA
Shrouded:
No
Wire Connection Type:
Screw Terminals
Terminal Designations:
Terminals identified in accordance with UL 498
Operating Temp.:
Maximum Continuous 75 C Minimum -40 C (w/o impact)
Wire Size:
#10 AWG
Weight (Lbs.):
0.35
Flammability:
UL 94 VO for Receptacles and Inlets. HB or better for Plugs and Connectors.
Spring Material:
.040 Brass"
Temp. Rise:
Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75.
Base Material:
Nylon Polyester
Lock Type:
Replacement-use
Industry Standard(s):
Certified to CSA C22.2 No.42 Fed.Spec. W-C-596 Listed to UL 498
Display Size:
Standard Sized Product
Current / Amperage Rating:
30 A
Application:
Heavy Duty Industrial
Environmental Conditions:
Indoor Dry Unless Protected By Additional Means
Dielectric Strength:
Withstands 2,000V minimum
Type:
Single Flush Receptacle
Connectivity:
Back Wired Screw Terminals
Voltage Rating Description:
3 Phase 250 VAC
Height:
1.36 in
Amperage Rating:
30 A
Length:
3.61 in
Dimensions:
3.61 in x 1.71 in x 1.36 in
Operating Temperature:
Maximum continuous 75°C and minimum -40°C without Impact
Material - Mounting Hardware:
Screw Mounting
OEM Brand Name:
Hubbell Wiring Device-Kellems
Width:
1.71 in
Performance:
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - V2 or better per UL94/CSA 22.2 No.0.17 Environmental - Moisture Re
Item Type:
30A Grounding Single Flush Receptacle
Package Quantity:
1
