3-Phase General Purpose Motor, 2 hp HP, 184T Frame, 230/460V AC Voltage, 1180 Nameplate RPM - 194143.00
DaytonLog in for pricing
(No reviews yet)
Write a Review
Dayton
3-Phase General Purpose Motor, 2 hp HP, 184T Frame, 230/460V AC Voltage, 1180 Nameplate RPM - 194143.00
General Purpose Motor, 3-Phase, Totally Enclosed Fan-Cooled Motor Enclosure Design, 2 hp HP, Nameplate RPM 1180, Frame 184T, Voltage 230/460V AC, 60 Hz Hz, Three Phase, Full Load Amps 6.1/3.1 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Cast Iron, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 88.5 Percent, Continuous Duty, 1,101-1,200, CE, CSA, UL
- Country of Origin:
- Multiple
- Item:
- General Purpose Motor
- Motor Enclosure Design:
- Totally Enclosed Fan-Cooled
- Motor Mounting Type:
- Rigid Base
- HP:
- 2 hp
- RPM Range:
- 1,101-1,200
- Voltage:
- 230/460V AC
- Frame:
- 184T
- Motor Thermal Protection:
- None
- Motor Service Factor:
- 1.15
- Voltage Compatibility:
- 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC
- Motor Application:
- General Application
- Motor Design:
- 3-Phase
- Nameplate RPM:
- 1180
- Motor Shaft Rotation:
- CW/CCW
- Motor Mounting Position:
- Horizontal
- Motor Frame Material:
- Cast Iron
- Motor Shaft Design:
- Keyed
- Standards:
- CE, CSA, UL
- No. of Speeds:
- 1
- Shaft Length:
- 2 3/4 in
- Footnotes:
- 12
- CC Number:
- CC003A
- Phase:
- Three
- Full Load Amps:
- 6.1/3.1 A
- Length Less Shaft:
- 13 1/16 in
- RPM Group:
- 1101-1200
- Inverter Rated:
- Yes
- Shaft Dia.:
- 1 1/8 in
- Green Environmental Attribute:
- Product Contributes To Reducing Energy Consumption
- Manufacturers Warranty Length:
- 3 yr
- Frame Material:
- Cast Iron
- Motor Bearings:
- Ball
- Green Certification or Other Recognition:
- NEMA Premium Rated
- Ins. Class:
- F
- Motor Efficiency Group:
- NEMA Premium Efficient
- Max. Ambient Temp.:
- 40 Degrees C
- Hz:
- 60 Hz
- Nominal Efficiency:
- 88.5 %
- Duty:
- Continuous
- Overall Length:
- 15 3/4 in
- Duty Cycle:
- Continuous
- Package Quantity:
- 1
-
-
