3 HP 3" Manual Electric Submersible Pump 220V No Switch Included - NK4-22 (220V)

Name: 3 HP 3" Manual Electric Submersible Pump 220V No Switch Included - NK4-22 (220V)
Brand: Tsurumi
SKU: NK4-22 (220V)
Price: 2615.09 USD
Availability: InStock

Tsurumi

SKU:

NK4-22 (220V)

UPC:

894787000298

Availability:

In Stock

(No reviews yet)

Manual Electric Submersible Pump, HP 3, Rated Voltage 220V AC, Hz 60, Phase - Pumps 1, Amps 13.00, Switch Actuation No Switch Included, Body Material Aluminum, Impeller Material Ductile Iron, Shaft Seal Material - Pumps Silicone Carbide, Flow Rate @ 5 Ft. of Head 130 gpm, Flow Rate @ 10 Ft. of Head 126 gpm, Flow Rate @ 15 Ft. of Head 120 gpm, Flow Rate @ 20 Ft. of Head 114 gpm, Max. Head 85 ft, Min. Sump Pit Dia. 14 in, Minimum Water Depth 14 in, Body Dia. 9 7/16 in

Country of Origin:: Japan
Cord Length:: 32 ft
Discharge NPT:: 3";Housing Material=Die Cast Aluminum"
HP:: 3
Hz:: 60
Impeller Material:: Ductile Iron
Max. Head:: 85 ft
Motor RPM:: 3465
Motor Type:: PSC
Shaft Seal:: Silicone Carbide
Voltage:: 220V
Phase:: 1
Insulation Class:: B
Pump Body Material:: Die Cast Aluminum
Input Phase AC:: 1
Item:: Manual Electric Submersible Pump
Duty:: Continuous
Impeller Material - Pumps:: Ductile Iron
Max. Liquid Temp.:: 104 Degrees F
GPM of Water @ 35 Ft. of Head:: 98
Width:: 9-7/16";GPM of Water @ 25 Ft. of Head=110"
Max. Diameter Solids:: 5/16 in
Thermal Protection:: Automatic
Max. Dia. Solids:: 5/16";Height=24-1/2""
Pump RPM:: 3465
GPM of Water @ 10 Ft. of Head:: 126
Length:: 24-1/2";Min. Sump Pit Dia.=14 in"
Cord Type:: 3-Conductor STOW, Resists Water and Oil
Amps:: 13.00
Amps - Pumps:: 13.00
Voltage - Pumps:: 240VAC
GPM of Water @ 15 Ft. of Head:: 120
GPM of Water @ 20 Ft. of Head:: 114
Cord Size:: 14/3
Switch Type - Pumps:: No Switch Included
GPM of Water @ 45 Ft. of Head:: 86
Handle:: Top Carrying
Agency Compliance:: Etl/Cetl
For Use With:: Nonflammable Liquids
Shaft Seal Material - Pumps:: Silicone Carbide
Diameter:: 9-7/16";Manufacturers Warranty Length=2 yr"
Max. Head - Pumps:: 85 ft.
Item - Dewatering Pumps:: Utility/Dewatering Pump
Base Material:: Steel
GPM of Water @ 40 Ft. of Head:: 92
GPM of Water @ 30 Ft. of Head:: 104
Switch Type:: No Switch Included
Cord Length - Pumps:: 32 ft.
Bearing Type:: Double Shielded, Permanently Lubricated, High Temperature C3 Ball Bearings Rated for a B-10 Life
GPM of Water @ 5 Ft. of Head:: 130
Discharge Standard:: NPT
Switch Actuation:: No Switch Included
Flow Rate @ 20 Ft. of Head:: 114 gpm
Rated Voltage:: 220V AC
Duty Cycle:: Continuous
Body Dia.:: 9 7/16 in
Phase - Pumps:: 1
Flow Rate @ 10 Ft. of Head:: 126 gpm
Width at Widest Point:: 9 7/16 in
Discharge:: 3 in MNPT
Body Material:: Aluminum
RPM:: 3,465 RPM
Minimum Water Depth:: 14 in
Discharge Gender:: Male
Flow Rate @ 15 Ft. of Head:: 120 gpm
Overall Height:: 24 1/2 in
Flow Rate @ 5 Ft. of Head:: 130 gpm
Discharge Dia.:: 3 in
Pump Type:: Construction Site and Residential Dewatering
Package Quantity:: 1
