2W 3P 20A Hazardous Location GFI Cover 120 VAC 5-20R - EFS275A-2023GFI

2W 3P 20A Hazardous Location GFI Cover 120 VAC 5-20R - EFS275A-2023GFI

Appleton Electric
SKU:
EFS275A-2023GFI
|
UPC:
781381671309
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
GFCI Receptacle, Circuit Breaker Yes, Current Rating 20 A, GFCI Yes, Hazardous Location Specification Class I, Div 1 and 2, Group C, D, Class II, Div 1 and 2, Group F, G, Class III, Div 1 and 2, Horsepower Rating 1 hp, Housing Material Copper-Free Aluminum, Hub Type Dead End, NEMA Enclosure Rating 3, 3R, 3RX, 7BCD, 9FG, NEMA Receptacle Configuration 5-20R, Number of Gangs 2, Number of Poles 3, Number of Wires 2, Resistance Properties Dust Ignition Proof, Explosion Proof, Voltage Rating 125V AC
Additional Information
Country of Origin:
Mexico
Item:
GFCI Receptacle
Voltage:
120 V AC
NEMA Rating:
3, 3R, 7BCD, 9EFG
Number of Wires:
2
Number of Poles:
3
NEMA Type:
5-20R
Amps:
20 A
Material:
Copper-Free Aluminum
Finish:
Baked Gray Epoxy Clad Finish
Hz:
60
Hub Size:
3/4 in
Mounting Box:
2 Gang, Copperfree Aluminum
Standards:
cUL Listed, UL Listed
Hub Style:
Dead-end
Screws:
Stainless Steel
For Environment:
Hazardous Location
Features:
Factory-Sealed
Horsepower Rating:
1 hp
Hub Diameter:
0.75 in
NEMA Enclosure Rating:
3, 3R, 3RX, 7BCD, 9FG
Housing Material Finish:
Epoxy Powder Coated
Circuit Breaker:
Yes
Number of Gangs:
2
Current Rating:
20 A
Includes Mounting Hardware:
Yes
Resistance Properties:
Dust Ignition Proof, Explosion Proof
GFCI:
Yes
Hub Type:
Dead End
Hazardous Location Specification:
Class I, Div 1 and 2, Group C, D, Class II, Div 1 and 2, Group F, G, Class III, Div 1 and 2
NEMA Receptacle Configuration:
5-20R
Voltage Rating:
125V AC
Housing Material:
Copper-Free Aluminum
NEC Certifications and Compliances:
Class I, Division 1 and 2, Groups C, D; Class II, Division 1 and 2, Groups E, F, G; Class III; NEMA 7CD, 9EFG
Option Materials:
1- or 2-gang copperfree (4/10 of 1% max.) aluminum bodies and covers available. See catalog pages for details
Standard Materials:
Malleable iron body and covers. Nylon 6/6 handle. Corrosion resistant stainless steel nameplate mounting bracket (optional)
Standard Finishes:
Tumbler switches have a triple-coat finish (1) zinc electroplate, (2) chromate, and (3) epoxy powder coat
Nameplate Mounting Bracket:
Make circuit description/identification easy and eliminate costly field installation (drilling/tapping) to accommodate circuit identification nameplates by using our bracket accessory. See catalog.
Package Quantity:
1
