2NC/1NO Safety Interlock Switch Nema 4, 4X, 12 IP 67 - XCSE7333

2NC/1NO Safety Interlock Switch Nema 4, 4X, 12 IP 67 - XCSE7333

Telemecanique Sensors
SKU:
XCSE7333
|
UPC:
785901719809
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Safety Interlock Switch, Actuating Key, Solenoid Locking, Contact Form 1NO/2NC, Actuator Length Key Dependent, Connection Type 1/2 in NPT Conduit, AC Contact Rating 6 A @ 300 V, Series XCSE, DC Contact Rating 3 A @ 300 V, Solenoid Voltage 120 V AC, Height 1.73 in, Width 3.86 in, Depth 5.75 in, NEMA Rating 12, 4, 4X, IP Rating IP67, Operating Temp. Range -13 Degrees to 158 Degrees F, Conduit Size 1/2 in NPT, Body Material Zamak, Head Material Zamak
Additional Information
Country of Origin:
France
Item:
Safety Interlock Switch
AC Contact Rating:
6 A @ 300 V
DC Contact Rating:
3 A @ 300 V
Solenoid Voltage:
120 V AC
Contact Form:
1NO/2NC
IP Rating:
IP67
Head Material:
Zamak
Depth:
5.75 in
Height:
1.73 in
Operating Force:
4.5 lb
Operating Temp. Range:
-13 Degrees to 158 Degrees F
Connection Type:
1/2 in NPT Conduit
Style:
Actuating Key, Solenoid Locking
Description/Special Features:
Dust Tight and Corrosion Resistant (Indoor/Outdoor) Enclosure, Orange LED - Green LED Pilot Light, Water Tight
Width:
3.86 in
Series:
XCSE
NEMA Rating:
12, 4, 4X
Standards:
CSA C22.2 No 14, EN 1088/ISO 14119, EN/IEC 60204-1, EN/IEC 60947-5-1, EN/ISO 12100, UL 508
Conduit Size:
1/2 in NPT
Body Material:
Zamak
Actuator Length:
Key Dependent
Material:
metal
Features:
(2) LED Pilot Lights (Green/Orange)
Electrical Connection:
1/2 in NPT Conduit
Mechanical Durability:
1000000 cycles
Shock Resistance:
10 gn 11 ms IEC 60068-2-27
Vibration Resistance:
5 gn 10-500 Hz)IEC 60068-2-6
Head Type:
key operated turret head
NEMA Enclosure Rating:
12, 4, 4X
Mechanical Operating Durability:
1,000,000
Overall Width:
3.86 in
Overall Height:
5.75 in
Circuitry Action:
Slow Action
Actuating Key Type:
Pivoting, Flat
Actuator Material:
Metal
Overall Depth:
1.73 in
Operating Temperature - Maximum:
158 Degrees F
Resistance Properties:
Corrosion Resistant, Dust Resistant, Shock Resistant, Vibration Resistant, Watertight
Manufacturer Warranty Length:
18 mo
Operating Temperature - Minimum:
-13 Degrees F
Contact Operation:
slow-break, break before make
Ambient Air Temperature For Operation:
-25-40°C
Solenoid Contacts Type And Composition:
1 NC + 1 NO slow-break, simultaneous)
Product Or Component Type:
safety switch
Protection Type:
overvoltage protection signalling circuit
Electrical Shock Protection Class:
class I EN/IEC 61140
Maximum Operating Rate:
10 cyc/mn for maximum durability
Maximum Actuation Speed:
0.5 m/s
Electromagnet Interlocking:
locking on de-energisation and unlocking on energisation of solenoid
Signalling Circuit Voltage:
110/240 V 95...264 V)
Contacts Type And Composition:
2 NC + 1 NO
Protective Treatment:
TC
Ambient Air Temperature For Storage:
-40-70°C
Component Name:
XCSE
Product Certifications:
CSA || UL
Supply Voltage Type:
AC/DC
Positive Opening:
with NC contact
Safety Level:
can reach category 4 with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach PL = e with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach SIL 3 with the appropriate monitoring system and
[Us] Rated Supply Voltage:
110/120 V - 20...10 %
Cable Entry:
2 entries tapped 1/2 NPT"
[Ithe] Conventional Enclosed Thermal Current:
6A
Supply Frequency:
50/60 Hz
Actuator Forcible Withdrawal Rtc:
2000 N
Number Of Poles:
3
Signalling Circuit Type:
AC
Load Factor:
1
Minimum Actuation Speed:
0.01 m/s
Minimum Actuator Force For Extraction:
20 N
Power Consumption In Va:
10 VA inrush || 10 VA sealed
[Uimp] Rated Impulse Withstand Voltage:
6 kV EN/IEC 60947-5-1
Ip Degree Of Protection:
IP67 conforming to EN/IEC 60529 and EN/IEC 60947-5-1
Short-Circuit Protection:
10 A cartridge fuse gG (gl)
[Ui] Rated Insulation Voltage:
250 VEN/IEC 60947-1 signalling circuit
Local Signalling:
for guard open/guard closed and locked 2 LEDs (green or orange)
Design:
rectangular
[Ie] Rated Operational Current:
0.55 A 125 V, DC-13, Q300 EN/IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q300 EN/IEC 60947-5-1 || 3 A 120 V, AC-15, B300 EN/IEC 60947-5-1 || 1.5 A 240 V, AC-15, B300 EN/IEC 60947-5-1
Signalling Circuit Consumption:
7 mA
Package Quantity:
1
