2NC/1NO Magnetically Actuated Safety Interlock Switch - XCSDMP7012

2NC/1NO Magnetically Actuated Safety Interlock Switch - XCSDMP7012

Telemecanique Sensors
SKU:
XCSDMP7012
|
UPC:
785901971993
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Magnetically Actuated Safety Interlock Switch, Series XCSDM, Switch Width 0.98 in, Switch Height 3.46 in, Switch Depth 0.52 in, Contact Form 1NO, 2NC, DC Contact Rating 0.1 A @ 24 V, Operating Temp. Range -13 Degrees to 185 Degrees F, Termination Type Pre-Cabled, Cable Length 6.56 ft, IP Rating IP66, IP67, Actuator Width 0.98 in, Actuator Height 3.46 in, Actuator Depth 0.52 in, On Sensing Distance 0.31 in, Off Sensing Distance 0.79 in, Body Material Plastic, Description/Special Features With LED
Additional Information
Country of Origin:
France
Item:
Magnetically Actuated Safety Interlock Switch
Series:
XCSDM
DC Contact Rating:
0.1 A @ 24 V
Contact Form:
1NO, 2NC
Height:
88 mm
Width:
25 mm
Depth:
13 mm
IP Rating:
IP66, IP67
Operating Temp. Range:
-13 Degrees to 185 Degrees F
Actuator Height:
3.46 in
Switch Width:
0.98 in
Switch Depth:
0.52 in
Description/Special Features:
With LED
Switch Height:
3.46 in
Actuator Depth:
0.52 in
Actuator Width:
0.98 in
Includes:
Actuator
Body Material:
Plastic
Off Sensing Distance:
0.79 in
Cable Length:
6.56 ft
Termination Type:
Pre-Cabled
Standards:
CSA, RoHS, UL Listed
On Sensing Distance:
0.31 in
Material:
plastic
Electrical Connection:
pre-cabled
Electrical Durability:
1200000 cycles
Shock Resistance:
30 gn 11 ms IEC 60068-2-27
Vibration Resistance:
10 gn 10-150 Hz)IEC 60068-2-6
Enclosure Material:
thermoplastic PBT
Number Of Poles:
3
Protective Treatment:
TH
[Ue] Rated Operational Voltage:
24 V DC
Local Signalling:
1 LED
Ip Degree Of Protection:
IP66 conforming to IEC 60529 || IP67 conforming to IEC 60529
Ambient Air Temperature For Operation:
-25-85°C
Insulation Resistance:
1000 MOhm
Electrical Shock Protection Class:
class II EN/IEC 61140
Breaking Capacity:
3 VA
Ambient Air Temperature For Storage:
-40-85°C
Contact Operation:
1 NC staggered
[Uimp] Rated Impulse Withstand Voltage:
2.5 kV EN/IEC 60947-5-1
[Sa] Assured Operating Distance:
8 mm
Resistance Across Terminals:
57 Ohm
Maximum [Ie] Rated Operational Current:
100 mA
Short-Circuit Protection:
500 mA external cartridge fuse gG (gl)
Maximum Switching Voltage:
100 V DC
Product Or Component Type:
coded magnetic switch
Product Certifications:
CSA || UL
Cable Material:
PVC
Maximum Sensitivity To Magnetic Fields:
0.3 mT
Safety Level:
can reach category 4 with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach PL = e with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach SIL 3 with the appropriate monitoring system and
Contacts Type And Composition:
2 NC + 1 NO
Contacts Material:
rhodium
Switching Capacity In Ma:
5...100 mA
Switching Frequency:
150 Hz
Size:
88 x 25 x 13 mm
Component Name:
XCSDMP
[Ui] Rated Insulation Voltage:
100 V DC
[Sar] Assured Tripping Distance:
20 mm
Approach Directions:
3 directions
Design:
rectangular, standard
Cable Composition:
6 x 0.25 mm²
Switch Type:
Coded Switch
Indicating Light:
LED
Body Style:
Rectangular
Manufacturer Warranty Length:
18 mo
On Sensing Distance - Maximum:
0.31 in
Overall Width:
0.98 in
Magnet Actuator Depth:
0.52 in
Operating Temperature - Maximum:
185 Degrees F
Magnet Actuator Width:
0.98 in
Magnet Actuator Height:
3.46 in
Off Sensing Distance - Maximum:
0.79 in
Overall Depth:
0.51 in
Operating Temperature - Minimum:
-13 Degrees F
Overall Height:
3.46 in
Package Quantity:
1
