2ISCC-075-075 Two-Piece Industry Standard Clamping Coupling - 2ISCC-075-075

2ISCC-075-075 Two-Piece Industry Standard Clamping Coupling - 2ISCC-075-075

Climax Metal Products
SKU:
2ISCC-075-075
|
UPC:
44861051214
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Rigid Shaft Coupling, Bore Diameter 1 3/4 in, Bore Diameter 2 3/4 in, Bore Type Round, Clearance Diameter 1.81 in, Coupling Construction Two-Piece, Coupling Material Carbon Steel, Coupling Outside Diameter 1 1/2 in, Different Bore Sizes No, Keyway Depth 1 Not Applicable, Keyway Depth 2 Not Applicable, Minimum Bore Diameter 3/4 in, Keyway Width 1 Not Applicable, Keyway Width 2 Not Applicable, Maximum Bore Diameter 3/4 in, Maximum Speed 4,000 RPM, Maximum Torque 1,850 in-lb
Additional Information
Country of Origin:
United States
Item:
Rigid Shaft Coupling
Shaft Locking Type - Couplings:
2 Piece Clamp
System of Measurement:
Inch
Bore Dia.:
3/4 in
Material - Couplings:
Steel
Outside Dia.:
1 13/16 in
Overall Length:
2 1/4 in
With Keyway / Without Keyway:
Without Keyway
Finish:
black oxide
Max. RPM:
4,000 RPM
Clearance Dia. (In.):
1-13/16
Clearance Dia.:
1.813 in
Screw Size (In.):
1/4-28 x 5/8
Material:
Steel
Type:
Two Piece Clamp Type, Without Keyway
Item - Rigid Shaft Couplings:
Rigid Shaft Coupling
Design:
(8) Socket Capscrews, Can Be Installed Without Disassembling any Machinery or Components
Machined From:
Bar Stock
Application:
For Applications where Alignment is Critical, Particularly when no Backlash is Desired and Flexibility is not Required, Useful when Timing, Joining and/or Aligning Shafts at Lower Speeds and Torque
Screw Size:
1/4-28"
Max. Torque (In.-Lbs.):
1850
Max. Torque:
1,850 in-lb
Standards:
Conflict Minerals and Materials Compliant, DFARS Compliant, REACH Compliant, RoHS3 Compliant
Screw Material:
Carbon Steel
Bore Tolerance:
+0.003 in / -0.000 in
Included Screws:
(4) Hex Socket Cap Screws
Keyway Depth 1:
Not Applicable
Bore Type:
Round
Zero Backlash:
Yes
Keyway Depth 2:
Not Applicable
Screw Material Grade:
4140
Maximum Speed:
4,000 RPM
Maximum Bore Diameter:
3/4 in
Bore Diameter 2:
3/4 in
Minimum Bore Diameter:
3/4 in
Keyway Width 2:
Not Applicable
Coupling Material Finish:
Black Oxide
Shaft Locking Type:
Clamp On
Bore Diameter 1:
3/4 in
Coupling Material Grade:
1211
Number of Locking Screws:
4
Keyway Width 1:
Not Applicable
Clearance Diameter:
1.81 in
Coupling Outside Diameter:
1 1/2 in
Coupling Construction:
Two-Piece
Maximum Torque:
1,850 in-lb
Screw Material Finish:
Black Oxide
Different Bore Sizes:
No
Coupling Material:
Carbon Steel
Screw Thread Size:
1/4-28"
Package Quantity:
1
