29PC 118° General Purpose Taper Length Drill Set Chicago-Latrobe 120 Steam Oxide HSS 1/16-1/2x1/64 - 69864

29PC 118° General Purpose Taper Length Drill Set Chicago-Latrobe 120 Steam Oxide HSS 1/16-1/2x1/64 - 69864

Chicago-Latrobe
SKU:
69864
|
UPC:
662355698648
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Taper Length Drill Bit Set, Drill Bit Size 1/16 in to 1/2 in x 1/64 in, Drill Bit Point Angle 118 Degrees , Radial Point, High Speed Steel, Black Oxide
Additional Information
Country of Origin:
United States
Item:
Taper Length Drill Bit Set
Number of Pieces:
29
Cutting Direction:
Right Hand
Drill Bit Point Angle:
118 Degrees
Drill Bit Material:
High Speed Steel
Drill Bit Dimension Type:
Fractional Inch
Point Type:
General Purpose
Depth x Dia. Ratio:
4xD
Sizes Included:
1/16, 5/64", 3/32", 7/64", 1/8", 9/64", 5/32", 11/64", 3/16", 13/64", 7/32", 15/64", 1/4", 17/64", 9/32", 19/64", 5/16", 21/64", 11/32", 23/64", 3/8", 25/64", 13/32", 27/64", 7/16", 29/64", 15/32", 31/64", 1/2""
List Number:
120
Drill Bit Size:
1/16 in to 1/2 in x 1/64 in
Flute Type:
Spiral
Standards:
Not Rated
Primary Material Application:
Cast Iron, Steel
Measurement System:
Fractional Inch
Material - Machining:
High Speed Steel
Shank Type - Machining:
Straight
Finish - Machining:
Black Oxide
Primary Material Application ISO Code:
K, P
Helix Angle:
28 Degrees
Coolant Fed:
Non-Coolant Through
Drill Diameter Tolerance:
+0.0000 in /-0.0005 in - +0.0000 in /-0.0010 in
Drill Length Class:
Taper Length
Drill Bit Point Type:
Radial Point
Material Grade - Machining:
General Purpose
Series:
120
Maximum Drilling Depth:
Variable
Drill Point Length:
0.0000 in
Thread Direction:
Right Hand
Package Quantity:
1
